Pure Wings 3 140mm PWM White, 1200 RPM, 57.4 CFM, 21.9 dBA, Cooling Fan
Performant, Progressive, Quiet
With low minimum rpm and high top-end speed, Pure Wings 3 140mm PWM White are the perfect addition to PCs for any application. The fan offers outstanding reliability and makes for a long-lasting, companion for your gaming system.
- Optimized fan frame for outstanding performance on radiators
- Newly designed fan blades and re-arranged angle for extraordinary air pressure
- Pure Wings 3 140mm PWM White can be operated with very low minimum rpm for very quiet operation
- Long life rifle bearing gives an operating lifetime of 80,000 hours
- Product conception, design and quality control in Germany
General data | |
Model | Pure Wings 3 140mm PWM White |
Dimensions (mm) | 140 |
Color option | White |
Lighting | - |
Fan speed @ 100% PWM / 12V (rpm) | 1200 |
Noise level @ 100% PWM / 12V (dB(A)) | 21.9 |
Air Flow @ 100% PWM / 12V (CFM / m3/h) | 57.4 / 97.5 |
Air Pressure @ 100% PWM / 12V (mm H2O) | 0.96 |
Mechanical specifications | |
Dimensions (L x W x H), (mm) | 140 x 140 x 25 |
Weight incl. fixed cables (g) | 180 |
Bearing technology | Rifle |
Motor technology | 4-pole fan motor |
Push pin fixing | - |
Screw fixing | √ |
Cables / Connectors | |
Daisy-chain compatible | - |
Lighting connector | - |
Connector | 4-pin PWM |
Cable length (mm) | 460 |
Cable sleeve | - |
Performance / Noise | |
Air Flow @ 100% PWM / 12V (CFM / m3/h) | 57.4 / 97.5 |
Air Pressure @ 100% PWM / 12V (mm H2O) | 0.96 |
Noise level @ 100% PWM / 12V (dB(A)) | 21.9 |
Lifespan (h / 25°C) | 80,000 |
Electrical specifications | |
Rated Voltage DC (V) | 12 |
Operating Voltage DC (V) | 5 - 13.2 |
Current consumption (A) | 0.06 |
Safety current (A) | 0.30 |
Input power (W) | 3.6 |
Rated Current LED (A) | - |
Accessories | |
3-pin to 4-pin 12V-connector | - |
12V to 7V adapter | - |
12V to 5V adapter | - |
Screws | 4 |
Push pins | - |
hard plastic washer | - |
Others | - |
Safety certification | |
Approvals | CE / RoHS / RU / UKCA / WEEE |
Environmental directives | |
RoHS | √ |
WEEE | √ |
Triman | √ |
Service | |
Warranty (Years) | 3 |
International hotline / free of charge | √ / DE, FR |
Logistics data and RRP | |
Article number | BL112 |
EAN code | 4260052190999 |
Dimensions, package (L x W x H), (mm) | 174 x 142 x 27 |
Gross weight, package (kg) | 0.21 |
