Q3, Socket LGA 1700, 28mm Height, 125W TDP, Copper CPU Cooler

Quantity:
  • SKU: 4500460
  • Manufacturer: DYNATRON
  • MPN: Q3
  • Availability: LOW STOCK
Starting At
$30.71
Quantity:
Q3, Socket LGA 1700, 28mm Height, 125W TDP, Copper CPU Cooler
The Dynatron Q3 CPU cooler is designed for Q3- 1U Active with coopper base
CPU Support Intel
CPU Socket LGA 1700
Solution 1U Server
Dimensions 90.0 x 90.0 x 28 mm
Weight 443.9g
Material Copper Heatsink with Skiving Fins
Fan Dimension Ø80.0 x 15.0 mm

Speed

At Duty Cycle 0~20%: 1000±200 RPM

At Duty Cycle 50%: 3500±10% RPM

At Duty Cycle 100%: 7000 RPM

Bearing Double Ball
Rated Voltage 12V

Power

At Duty Cycle 0~20%: 0.60 W
At Duty Cycle 50%: 3.84 W
At Duty Cycle 100%: 19.2 W

Air Flow

At Duty Cycle 0~20%: 6.5 CFM
At Duty Cycle 50%: 11.2 CFM
At Duty Cycle 100%: 22.28 CFM
Noise Level At Duty Cycle 0~20%: 21.5 dBA
At Duty Cycle 50%: 43.0 dBA
At Duty Cycle 100%: 59.14 dBA

Static Pressure

At Duty Cycle 0~20%: 2.27 mm-H2O
At Duty Cycle 50%: 18.56 mm-H2O
At Duty Cycle 100%: 74.18 mm-H2O
Lead Wire Pin Out Pin1-Black (-)
Pin2-Yellow (+)
Pin3-Green (Techometer/Signal output)
Pin4-Blue (PWM
