RM42300-F, 3x 5.25", 5x 3.5" Drive Bays, No PSU, ATX, Black, 4U Chassis

SKU: 3584441

Manufacturer: CHENBRO

MPN: RM42300-F

Availability: Available


Price: $168.80
or as low as $5/month
Quantity:
  • Supports M/B up to 12” x 9.6”
  • Available for rackmount and stand-alone installation
  • Dedicated 80 mm fan for center front HDD cooling
  • Shock isolated dampener solution on internal HDD and device protection
  • Card retainer to hold low profile and full height add-on cards
  • Front 120mm fan with filter for add-on card cooling
  • Optional second 3 x 5.25” drive cage for maximum configuration flexibility
  • Supports 1-door or 2-door front bezel configuration
  • Supports PS/2 single or mini-redundant PSU
Form Factor 4U
MB Form Factor ATX (12” x 9.6”)
Dimensions (D x W x H) 465.2 x 430.0 x 176.0 (mm)
18.32” x 16.93” x 6.93”
Drive Bays External 3.5":1
External 5.25":3
Internal 3.5":4
Slim ODD:1
PSU Form Factor PS/2 Single or Mini-redundant
Indicators 1 x Power Status
1 x HDD Activity
2 x LAN Activity
Front Control 1 x Power On/Off
1 x System Reset
2 x USB 2.0/USB3.0(option)
System Security Intrusion Switch, Key lock on front door
Cooling Fans Front: 1 x 120mm (T=25mm), PWM, Rear: 2 x 80mm (T=25mm)(Option)
Expansion Slots 7
HDD Backplane N/A
Net Weight 9.5kg
Gross Weight 12.3kg
Front Bezel Option
Cubic Feet 3.44
Container Loading (Single Packing) 20’: 288, 40’: 598, 40’H: 678
