ROG STRIX GS-AX5400, IEEE 802.11ax, Dual-Band 2.4 / 5GHz, 574 / 4804 Mbps, 4xRJ45, USB 3.2, Wireless Router

Quantity:
  • SKU: 15130887
  • Manufacturer: ASUS
  • MPN: ROG STRIX GS-AX5400
  • Availability: TEMPORARILY OUT OF STOCK
Starting At
$265.10
Quantity:
ROG STRIX GS-AX5400, IEEE 802.11ax, Dual-Band 2.4 / 5GHz, 574 / 4804 Mbps, 4xRJ45, USB 3.2, Wireless Router

ASUS ROG STRIX GS-AX5400. Get the competitive edge with ROG Strix GS-AX5400, a WiFi 6 gaming router that gives you the fastest, smoothest WiFi gaming connections ever. With ultrafast WiFi speeds up to 5400 Mbps, it's ready for the most intense matches, and with fully customizable ASUS Aura RGB lighting effects, it looks great too. If you take gaming seriously, you need the GS-AX5400!

  • New-generation WiFi 6 – Enjoy ultrafast speeds up to 5400 Mbps with 160 MHz WiFi 6 channels
  • Fully optimized gaming – Mobile Game Mode, dedicated Gaming Port and Gear Accelerator let you optimize any type of gaming on mobile, console or PC
  • VPN Fusion – Run a VPN and an ordinary internet connection simultaneously, allowing maximum speed even if other network users need to use a VPN
  • More privacy, anywhere – Instant Guard secures public WiFi connections anywhere in the world using GS-AX5400, with just a click
  • ASUS AiMesh support – Create a flexible, seamless whole-home mesh network with AiMesh-compatible routers
Model Name GS-AX5400
Network Standard IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11ax
IPv4
IPv6
Product Segment AX5400 ultimate AX performance : 4804 Mbps+ 574 Mbps
AX technology Yes
Data Rate 2.4GHz N: 2x2 (Tx/Rx) 1024 QAM 20/40MHz, up to 500Mbps
5GHz AC: 4x4 (Tx/Rx) 1024 QAM 20/40/80MHz, up to 2167Mbps
2.4GHz AX: 2x2 (Tx/Rx) 1024 QAM 20/40MHz, up to 574Mbps
5GHz AX: 4x4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps
Antenna External antenna x 4
Transmit/Receive 2.4 GHz 2 x 2
5 GHz 4 x 4
Processor 1.5 GHz tri-core processor
Memory 256 MB Flash 512 MB RAM
Boosts speed OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth
Operating Frequency 2.4G Hz / 5 GHz
Ports RJ45 for Gigabits BaseT for WAN x 1 RJ45 for Gigabits BaseT for LAN x 4 USB 3.2 Gen 1 x 1
Button WPS Button Reset Button Power Switch
LED Indicator Power x 1 2.4G x 1 5G x 1 WAN x 1
Power Supply AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 1.75 A current
Package content GS-AX5400 Router RJ-45 cable Power adapter Warranty card Quick start guide
Product Weight (g) 701.3 g
AiMesh AiMesh
Primary AiMesh router
AiMesh node
Router APP ASUS Router APP
Game Game Boost/acceleration
ROG_First
OpenNAT (Game Profile)
Gaming port
Alexa Support Alexa skill
AiProtection AiProtection Pro
Router Security Assessment
Malicious site blocking
Two-Way IPS
Infected Device Prevention and Blocking
Parental Control Parental Control
Parental Control Customized Internet schedule
Traffic Control Adaptive QoS
Bandwidth Monitor
Bandwidth limiter
Maximum Bandwidth limiter rule : 32
Traditional QoS
Maximum Traditional QoS rule : 32
Traffic Monitor
Real-time traffic monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer
Traffic analysis period : Daily, Weekly, Monthly
Website history
Wireless IPv6
MU-MIMO
WiFi Encryption : WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support
UTF-8 SSID
Guest Network
Maximum Guest Network rule : 2.4GHz x3, 5GHz x3
Guest Network Connection time limit
WPS
Wi-Fi MAC address filter
Maximum MAC filters : 64
Wireless scheduler
Wi-Fi Radar
Airtime fairness
Universal beamforming
WAN Explicit beamforming
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN
WAN Aggregation
3G/4G LTE dongle
Android tethering
Port forwarding
Maximum port forwarding rule : 64
Port triggering
Maximum port triggering rule : 32
DMZ
DDNS
NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, PPPoE relay
LAN DHCP Server
IGMP snooping
IPTV
LAN Link Aggregation
Manually assign IP address
Maximum manually assign IP address rule : 64
VPN VPN Client L2TP
VPN Client OVPN
VPN Client PPTP
VPN Server IPSec
VPN Server OVPN
VPN Server PPTP
VPN Fusion
USB application File System : HFS+, NTFS, vFAT, ext2, ext3, ext4
HDD hibernation
Safely Remove disk
AiCloud
Download master
AiDisk
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder privileges
Administration Operating mode : Wireless router mode Access point mode Media bridge mode Repeater mode AiMesh node mode
Operating system : ASUSWRT
Free OS upgrade
Firewall
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL)
SSH
Configuration backup and restore
Diagnosis tools
Feedback system
System log
