Radeon™ RX 7700 XT SPEEDSTER QICK 319, 1785 - 2565MHz, 12GB GDDR6, Graphics Card
GAME. STREAM. ADVANCE.
Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon 7700 XT graphics cards, powered by the AMD RDNA™ 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with up to 12GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort™ 2.1 technology.
Manufacturer | |
Manufacturer | XFX |
Model Number | RX-77TQICKB9 |
Product Name | AMD Radeon™ RX 7700 XT |
Product Description | XFX SPEEDSTER QICK319 RADEON RX 7700 XT BLACK Gaming Graphics Card with 12GB GDDR6 HDMI 3xDP, AMD RDNA™ 3 |
Short Description | XFX SPEEDSTER QICK319 RADEON RX 7700 XT BLACK |
Launch Date | September 6, 2023 |
UPC Number | 840191502453 |
Specifications | |
Bus Type | PCI-E 4.0 |
Primary Clock Speeds | |
Base Clock Up To | 1785 MHz |
Game Clock Up To | 2276 MHz |
Boost Clock Up to | 2599 MHz |
Stream Processors | 3456 |
Compute Units | 54 |
Memory Bus | 192bit |
Memory Clock | 18 Gbps |
Memory Size | 12 GB |
Memory Bandwidth | Up to 432 GB/s |
Effective Memory Bandwidth | Up to 1995 GB/s |
Memory Type | GDDR6 |
Card Profile | 2.5 slot |
Thermal Solution | 3 Fan |
*"Game Clock" is the expected GPU clock when running in typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary. **"Boost Clock" is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads. |
|
Outputs | |
DisplayPort 2.1 | 3x |
HDMI™ 2.1 | 1x |
Requirements | |
External Power | 2x PCI-E 8 pin connections |
Minimum Power Supply Requirement | 700 watt |
Certifications | |
RoHS | |
Package Contents | |
Warranty card - QR Code Insert | 1x |
Estimated Dimensions & Weights | |
Card Dimension (cm) | 33.5 x 13 x 5.2 |
Card Dimension (inch) | 13.2 x 5.1 x 2 |
Master Carton Dimensions (cm) | 46 x 39.5 x 47.5 |
Master Carton Dimensions (inch) | 18.11 x 15.55 x 18.7 |
Master Carton Weight (Kg) | ~11.58 |
Master Carton Weight (lb) | ~25.53 |
Package Dimensions (cm) | 44.5x 23.5 x 12.5 |
Package Dimensions (inch) | 17.51 x 9.25 x 4.92 |
Package Weight (Kg) | ~1.68 |
Package Weight (lb) | ~3.7 |
Units/Carton | 6 |
Technologies | |
60 AMD RDNA™ 3 Compute Units(with RT+AI Accelerators) AMD Infinity Cache™ technology DisplayPort™ 2.1 AMD Radiance Display™ Engine AMD Radeon™ Boost technology* AMD Radeon™ Anti-Lag* technology* 16GB GDDR6 on 256-Bit Memory Bus PCI® Express 4.0 ready AMD FidelityFX™ technologies* AMD FidelityFX™ Super Resolution technology* Microsoft® DirectX® 12 Ultimate Microsoft® DirectStorage Vulkan® Optimized AMD smart technologies* AMD Software Adrenalin Edition™ application AMD Noise Suppression* AMD Privacy View* AMD Radeon™ Super Resolution technology* AMD Link* AMD Freesync™ technology* |
