General Specifications | |
---|---|
Platform | Desktop |
Market Segment | Mainstream Desktop |
Product Family | AMD Ryzen™ Processors |
Product Line | AMD Ryzen™ 5 Desktop Processors |
Consumer Use | Yes |
Regional Availability | Global, China, NA, EMEA, APJ, LATAM |
Former Codename | "Renoir" |
Architecture | "Zen 2" |
# of CPU Cores | 6 |
Multithreading (SMT) | Yes |
# of Threads | 12 |
Max. Boost Clock | Up to 4.1GHz |
Base Clock | 3.6GHz |
L1 Cache | 384KB |
L2 Cache | 3MB |
L3 Cache | 8MB |
Default TDP | 65W |
Processor Technology for CPU Cores | TSMC 7nm FinFET |
CPU Compute Die (CCD) Size | 180mm² |
Package Die Count | 1 |
Unlocked for Overclocking | Yes |
CPU Socket | AM4 |
Socket Count | 1P |
Supporting Chipsets | X570 X470 X370 B550 B450 B350 A520 A320 |
CPU Boost Technology | Precision Boost 2 |
Instruction Set | x86-64 |
Supported Extensions | AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
Thermal Solution (PIB) | AMD Wraith Stealth |
Max. Operating Temperature (Tjmax) | 95°C |
Launch Date | |
*OS Support | Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer. |
Connectivity | |
USB Type-C® Support | Yes |
Native USB 3.2 Gen 2 (10Gbps) Ports | 4 |
Native USB 3.2 Gen 1 (5Gbps) Ports | 0 |
Native USB 2.0 (480Mbps) Ports | 0 |
Native SATA Ports | 2 |
PCI Express® Version | PCIe 3.0 |
Native PCIe® Lanes (Total/Usable) | 24/20 |
Additional Usable PCIe Lanes from Motherboard |
AMD X570
16x Gen 3 AMD X4702x Gen 3 AMD X4708x Gen 2 |
NVMe Support | Boot, RAID0, RAID1, RAID10 |
System Memory Type | DDR4 |
Memory Channels | 2 |
Max. Memory | 128GB |
System Memory Subtype | UDIMM |
System Memory Specification | Up to 3200MHz |
Max Memory Speed |
2x1R
DDR4-3200 2x2RDDR4-3200 4x1RDDR4-2933 4x2RDDR4-2667 |
ECC Support | No |
Graphics Capabilities | |
Integrated Graphics | No |
Graphics Model | Discrete Graphics Card Required |
Product IDs | |
Product ID Boxed | 100-100000644BOX |
Product ID Tray | 100-000000644 |
Key Features | |
Supported Technologies | AMD StoreMI Technology AMD "Zen 2" Core Architecture AMD Ryzen™ VR-Ready Premium |
