General Specifications | ||
Platform | Desktop | |
Market Segment | Enthusiast Desktop | |
Product Family | AMD Ryzen™ Processors | |
Product Line | AMD Ryzen™ 5 Processors | |
AMD PRO Technologies | No | |
Consumer Use | Yes | |
Regional Availability | Global | |
Former Codename | "Raphael AM5" | |
Architecture | "Zen 4" | |
# of CPU Cores | 6 | |
Multithreading (SMT) | Yes | |
# of Threads | 12 | |
Max. Boost Clock | Up to 5.1GHz | |
Base Clock | 3.8GHz | |
L1 Cache | 384KB | |
L2 Cache | 6MB | |
L3 Cache | 32MB | |
Default TDP | 65W | |
Processor Technology for CPU Cores | TSMC 5nm FinFET | |
Processor Technology for I/O Die | TSMC 6nm FinFET | |
CPU Compute Die (CCD) Size | 71mm² | |
I/O Die (IOD) Size | 122mm² | |
Package Die Count | 2 | |
Unlocked for Overclocking | Yes | |
AMD EXPO™ Memory Overclocking Technology | Yes | |
Precision Boost Overdrive | Yes | |
Curve Optimizer Voltage Offsets | Yes | |
AMD Ryzen™ Master Support | Yes | |
CPU Socket | AM5 | |
Supporting Chipsets | X670E X670 B650E B650 |
|
CPU Boost Technology | Precision Boost 2 | |
Instruction Set | x86-64 | |
Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 | |
Max. Operating Temperature (Tjmax) | 95°C | |
Launch Date | ||
*OS Support | Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer. |
|
Connectivity | ||
USB Type-C® Support | Yes | |
Native USB 3.2 Gen 2 (10Gbps) Ports | 4 | |
Native USB 3.2 Gen 1 (5Gbps) Ports | 0 | |
Native USB 2.0 (480Mbps) Ports | 1 | |
Native SATA Ports | 0 | |
Native PCIe® Lanes (Total/Usable) | 28/24 | |
Additional Usable PCIe Lanes from Motherboard | AMD X670E | 12x Gen4 |
AMD X670 | 12x Gen4 | |
AMD B650E | 8x Gen4 | |
AMD B650 | 8x Gen4 | |
NVMe Support | Boot, RAID0, RAID1, RAID10 | |
System Memory Type | DDR5 | |
Memory Channels | 2 | |
Max. Memory | 128GB | |
System Memory Subtype | UDIMM | |
Additional Usable PCIe Lanes from Motherboard | 2x1R | 5200 MT/s |
2x2R | 5200 MT/s | |
4x1R | 3600 MT/s | |
4x2R | 3600 MT/s | |
ECC Support | Yes (Requires mobo support) | |
Graphics Capabilities | ||
Integrated Graphics | Yes | |
Graphics Model | AMD Radeon™ Graphics | |
Graphics Core Count | 2 | |
Graphics Frequency | 2200 MHz | |
GPU Base | 400 MHz | |
USB Type-C® DisplayPort™ Alternate Mode | Yes | |
Product IDs | ||
Product ID Boxed | 100-000000592 | |
Key Features | ||
Supported Technologies | AMD EXPO™ Technology
AMD Ryzen™ Technologies
|
