Target Applications Small and medium-sized business applications, including web servers, file and print servers, e-mail servers, storage servers and vertical-specific business applications. CPU-Frequency intensive HPC workloads (Life Science, Financial Service, Seismic Imaging).
Green Compliant | Yes |
Green Compliance Certificate/authority | WEEE |
Number Of External 5.25 Bays | 1 |
Chipset Manufacturer | Intel |
Chipset Model | 5500 |
Graphics Controller Model | Server Engine |
Number Of Power Supplies Installed | 1 |
Number Of Total Memory Slots | 8 |
Graphics Memory Capacity | 64 MB |
Graphics Memory Technology | DDR2 SDRAM |
Number Of Processors Supported | 2 |
Raid Supported | Yes |
Ethernet Technology | Gigabit Ethernet |
Number Of Total Expansion Bays | 3 |
Number Of 3.5 Bays | 2 |
Number Of Total Expansion Slots | 1 |
Number Of Pci Express X8 Slots | 1 |
Network rj-45 | Yes |
Maximum Power Supply Wattage | 400 W |
Total Number Of Usb Ports | 1 |
Memory Standard | DDR3-1333/PC3-10600 |
Height | 1.7" |
Width | 16.9" |
Depth | 20.0" |
Memory Technology | DDR3 SDRAM |
Processor Socket | Socket B LGA-1366 |
Rack Height | 1U |
Form Factor | Rack-mountable |
Manufacturer | Intel Corporation |
Product Model | SR1630BCRNA |
Processor Supported | Xeon |
Product Line | Server System |
Raid Levels | 0, 1, 10 |
Controller Type | Serial ATA/300 |
Manufacturer Part Number | SR1630BCRNA |
Manufacturer Website Address | www.intel.com |
Package Contents | Server System SR1630BCRNA Barebone System Basic Rail Kit Pre-routed Cables Slim-line CD-ROM Bay North American Power Cord Intel Server Chassis SR1630 1 x Low-profile PCI Express Riser Card 400-Watt Non-Redundant High Efficiency Power Supply |
Additional Information | Quick Path Technology: Quick Path Interconnect Protocol up to 6.4 GT/s |
