SX1000, 80 PLUS Platinum 1000W, Fully Modular, SFX-L Power Supply

Quantity:
  • SKU: 13789850
  • Manufacturer: SILVERSTONE
  • MPN: SST-SX1000-LPT
  • Availability: LOW STOCK
Starting At
$297.84
Quantity:
SX1000, 80 PLUS Platinum 1000W, Fully Modular, SFX-L Power Supply

SilverStone SX1000 (SST-SX1000-LPT). 80 PLUS Platinum 1000W fully modular SFX-L power supply.

  • SFX-L form factor for use in small form factor computers
  • 1000W continuous power output rated for 24/7 operation
  • Class-leading single +12V rail with 83.3A
  • High efficiency with 80 PLUS Platinum certification
  • Silent running 120mm dual ball bearing fan with advanced semi-fanless operation
  • 100% modular short cables with flexible flat arrays
  • Strict ±3% voltage regulation and low ripple & noise
  • 24/7 continuous power output with 50? operating temperature
  • High quality construction with all Japanese capacitors
Product No. SST-SX1000-LPT
Max. DC Output 1000W
Power density 969W per liter
Load Range
  +3.3V +5V +12V +5VSB -12V
Max.(Amps) 25A 25A 83.3A 3.0A 0.3A
Peak (Amps) / / / / /
Min.(Amps) 0A 0A 0A 0A 0A
Range (%) ±3% ±3% ±3% ±5% ±10%
Line Reg.(%) ±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p) 40mV 40mV 100mV 40mV 80mV
Model (on safety) SST-SX1000-LPT
Color Black(Lead-Free Paint)
Combined +3.3V & +5V 125W
Combined +12V 999.6W
Input Voltage 90V ~ 264V
Input Frequency Range 47Hz ~ 63Hz
PFC Active PFC(PF>0.9 at full load)
Efficiency 89% ~ 92% at 20% ~ 100% loading
MTBF 100,000 hours
Operating temperature 0°C ~ 50°C
Protection Over current protection
Over power protection
Over voltage protection
Short circuit protection
Over temperature protection
Connectors 1 x 24 / 20-Pin motherboard connector(300mm)
2 x 8 / 4-Pin EPS / ATX 12V connector("400mm" x 2)
6 x 8 / 6-Pin PCIE connector("400mm / 150mm" x 3)
8 x SATA connector("300mm / 200mm / 100mm / 100mm" x 2)
3 x 4-Pin Peripheral connector(300mm / 200mm / 200mm)
1 x 4-Pin Floppy adapter connector(100mm)
Cooling System Single 120mm dual ball bearing fan
Form factor SFX-L
Noise Level 0 ~ 36 dBA
Dimension 125 mm (W) x 63.5 mm (H) x 130 mm (D)
4.92" (W) x 2.5" (H) x 5.12" (D)
Weight 1.68 Kg
Certification 80 PLUS Platinum
Other GPU Support list
Compatible with ATX12V v2.4
