Silent Wings Pro 4 120mm PWM White, 3000 RPM, 83.9 CFM, 36.9 dBA, Cooling Fan

Quantity:
  • SKU: 17577286
  • Manufacturer: be quiet!
  • MPN: BL118
  • Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$27.71
Quantity:
Silent Wings Pro 4 120mm PWM White, 3000 RPM, 83.9 CFM, 36.9 dBA, Cooling Fan

Silent Wings Pro 4 120mm PWM White is the most progressive, performant and versatile fan by be quiet!

  • Optimized fan blades for the highest performance on radiators and heat sinks
  • Speed switch allows changing maximum PWM speed between medium-speed, high-speed and ultra-high-speed (up to 3000 rpm)
  • Small tip clearance and a fan frame with a funnel-shaped air outlet for extremely high air pressure
  • Virtually inaudible operation at regular speed
  • 6-pole fan motor and fluid-dynamic bearing for less vibration and very smooth operations
  • Individual mounting systems for use as a case fan or with a radiator
General data
Model Silent Wings Pro 4 120mm PWM White
Dimensions (mm) 120
Color option White
Lighting -
Fan speed at 100% PWM / 12V (rpm) 3000
Noise level at 100% PWM / 12V ( dB(A) ) 36.9
Airflow at 100% PWM / 12V ( CFM / m3/h ) 83.9 / 142.5
Air Pressure at 100% PWM / 12V ( mm H2O ) 5.31
Mechanical specifications
Dimensions (L x W x H), (mm) 120 x 120 x 25
Weight incl. fixed cables (g) 227
Bearing technology FDB
Motor technology 6-pole fan motor
Push pin fixing
Screw fixing
Cables / Connectors
Daisy-chain compatible -
Lighting connector -
Connector 4-pin PWM
Cable length (mm) 500
Cable sleeve
Performance / Noise
Airflow at 100% PWM / 12V ( CFM / m3/h ) 83.9 / 142.5
Air Pressure at 100% PWM / 12V ( mm H2O ) 5.31
Noise level at 100% PWM / 12V ( dB(A) ) 36.9
Lifespan (h / 25°C) 300,000
Zero RPM mode
Electrical specifications
Rated Voltage DC (V) 12
Operating Voltage DC (V) 7 - 13.2
Current consumption (A) 0.30
Safety current (A) 0.33
Input power (W) 3.6
Rated Current LED (A) -
Accessories
3-pin to 4-pin 12V-connector -
12V to 7V adapter -
12V to 5V adapter -
Screws 4
Push pins 4
hard plastic washer 4
Others Rubber & hard plastic & radiator mountings
Safety certification
Approvals CE  /  RoHS  / RU / UKCA / TÜV /  WEEE
Environmental directives
RoHS
WEEE
Triman
Service
Warranty (Years) 5
International hotline / free of charge √ / DE, FR, US
Logistics data and RRP
Article number BL118
EAN code 4260052191095
Dimensions, package (L x W x H), (mm) 192 x 141 x 31
Gross weight, package (kg) 0.40
