Single-Phase Basic Power Distribution Unit, 1U Rack-Mount, 13x / NEMA 5-15R, 120V AC, 50/60Hz, 15A, 15-ft cord, Black
- SKU: 4291
- Manufacturer: TRIPP LITE
- MPN: PDU1215
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
The PDU1215 1.8kW Single-Phase 120V Basic PDU is the perfect no-frills unit for networking, telecom, security, audio/video and sound reinforcement applications. Perfectly suited for high-density IT environments, the PDU1215 features a single breakered load bank with 13 NEMA 5-15R outlets—12 in the rear and one in front. The NEMA 5-15P input plug with long 15-foot(4.5 m) cord connects to your facility’s compatible AC power source, generator or protected UPS to distribute power to connected equipment.
The switchless design prevents an accidental shutdown, which could lead to costly downtime. A 15A circuit breaker protects connected equipment from dangerous overloads. The reversible all-metal housing mounts in 1U of space in EIA-standard 19-inch racks, as well as on a wall or workbench or under a counter. With a compatible rack and Tripp Lite’s PDUSIDEBRKT accessory(sold separately), you can adapt the PDU1215 for vertical 0U rack-mounting.
eliable Single-Phase Power Distribution
- Ideal no-frills PDU for networking, telecom, security, audio/video and sound reinforcement applications
- 13 NEMA 5-15R outlets in one breakered load bank
- 15A circuit breaker protects outlets against overloads
- NEMA 5-15P input plug with 15 ft. cord
- Rear-panel grounding lug
Switchless Design
- Prevents accidental shutdowns and costly downtime
Versatile Installation Options
- Mounts horizontally in 1U of EIA-standard 19 in. 2- and 4-post racks
- Reversible all-metal housing faces front or rear in rack
- Ready for toolless 0U vertical installation with optional PDUSIDEBRKT(sold separately)
- Also mounts on wall, workbench or under a counter
Package Includes
- PDU1215 1.8kW Single-Phase 120V Basic PDU
- Mounting hardware
- Owner’s manual
| OVERVIEW | |
|---|---|
| PDU Type | Basic |
| OUTPUT | |
| Output Capacity Details | 1.9kW (127V), 1.8kW (120V), 1.5kW (100V) / 15A total capacity |
| Frequency Compatibility | 50 / 60 Hz |
| Output Receptacles | (13) 5-15R |
| Output Nominal Voltage | 100; 120; 127 |
| Overload Protection | 15A breaker |
| INPUT | |
| PDU Input Voltage | 100; 120; 127 |
| Recommended Electrical Service | 15A 120V |
| Maximum Input Amps | 15 |
| PDU Plug Type | NEMA 5-15P |
| Input Cord Length (ft.) | 15 |
| Input Phase | Single-Phase |
| USER INTERFACE, ALERTS & CONTROLS | |
| Switches | No power switch |
| PHYSICAL | |
| Minimum Required Rack Depth (inches) | 7.5 |
| Shipping Dimensions (hwd / in.) | 2.2 x 20.4 x 9.3 |
| Shipping Weight (lbs.) | 5.2 |
| Unit Dimensions (hwd / in.) | 1.75 x 17.5 x 4.5 |
| Unit Weight (lbs.) | 4.9 |
| Material of Construction | Metal |
| Form Factors Supported | 1U rackmount, 0U vertical rackmount, wall-mount and undercounter installation supported |
| PDU Form Factor | Horizontal (1U, 2U, etc) |
| Outlets Measurement (Center to Center) | 30.2mm |
| ENVIRONMENTAL | |
| Storage Temperature Range | 5 to 122F (-15 to 50C) |
| Relative Humidity | 5 to 95% non-condensing |
| Operating Elevation (ft.) | 0-10,000 |
| SPECIAL FEATURES | |
| TVSS Grounding | Back panel grounding lug |
| CERTIFICATIONS | |
| Certifications | Tested to UL60950-1 (USA), CSA-C22.2 (Canada) |
| WARRANTY | |
| Product Warranty Period (Worldwide) | 5-year limited warranty |
