Smart App LCD OR1500LCDRM1U, 1500VA/900W, 120V, 6 Outlets, Black, 1U Rackmount UPS

SKU: 1343615



Availability: Available

Price: $409.95
or as low as $13/month

1500VA/900W Smar App UPS AVR LCD 1U

  • Capacity: 1500 VA / 900 W
  • Topology: Line Interactive
  • Waveform: Simulated Sine Wave
  • Plug type & cord: NEMA 5-15P, 10 ft. cord
  • Outlet types: 6 × NEMA 5-15R
  • Communication: USB, Serial, SNMP
  • Management software: PowerPanel® Business
  • Remote management: Yes
  • Warranty: 3 year
Energy Saving GreenPower UPS™ Bypass
Energy Star Certified Yes
UPS Topology Line Interactive
Battery Quantity 4
Battery Size 6V/9Ah
Battery Type Sealed Lead-Acid
Hot Swappable Yes
Replacement Battery Cartridge RB0690X4
Replacement Battery Cartridge Quantity 1
Runtime at Full Load (min) 2
Runtime at Half Load (min) 11
Typical Recharge Time 8 hours
User Replaceable Yes
Physical Dimensions – (WxHxD) (cm) 43.82 x 4.45 x 49.53 (cm)
Physical Dimensions – (WxHxD) (in) 17.25 x 1.75 x 19.5 (in)
Physical Dimensions – (WxHxD) (mm) 438 x 44 x 495 (mm)
Weight (kg) 14.97
Weight (lb) 33
Dimensions – Shipping
Shipping – Weight (kg) 22.68
Shipping – Weight (lb) 50
Shipping Dimensions – (WxHxD) (cm) 54.61 x 15.88 x 60.33 (cm)
Shipping Dimensions – (WxHxD) (in) 21.5 x 6.25 x 23.75 (in)
Shipping Dimensions – (WxHxD) (mm) 546.1 x 158.75 x 603.25 (mm)
Adjustable Voltage Range 88-144Vac
Circuit Breaker 15A
Cord Length (ft) 10
Frequency Range 57-63Hz
Input Voltage Range 90-140Vac
Nominal Input Voltage 120Vac
Plug Style Straight
Plug Type NEMA 5-15P
Automatic Voltage Regulation Yes
On Battery Frequency 60Hz ± 1%
On Battery Voltage 120Vac ± 10%
On Battery Waveform Simulated Sine Wave
Outlet Type NEMA 5-15R
Outlets – Battery & Surge Protected 4
Outlets – Surge-Only Protected 2
Outlets – Total 6
Overload Protection Internal Circuitry Limiting, Circuit Breaker
Transfer Time Typical 8ms
VA 1500
Watts 900
Surge Protection & Filtering
EMI/RFI Filtration Yes
Network Protection RJ45 1-in, 1-Out (10/100/1000)
Surge Suppression (Joules) 1150
Management & Communications
Audible Alarms On Battery, Low Battery, Overload, Fault
Dry Contact Port Yes
Environmental Sensor Yes, with optional RMCARD205 & ENVIROSENSOR
HID Compliant USB Port Yes
LED Indicators Power On, Wiring Fault
Management Cable USB Cable
Multifunction LCD Panel Yes
SNMP / HTTP Remote Monitoring Yes, with optional RMCARD205
Software PowerPanel® Business
Form Factor Rackmount
Rack Size 1U
Operating Elevation 0-10,000 ft (0-3,000 m)
Operating Relative Humidity 0 – 95% (non-condensing)
Operating Temperature 32 °F to 104 °F (0 °C to 40 °C)
Storage Elevation 0-50,000 ft (0-15,000 m)
Storage Relative Humidity 0 – 95% (non-condensing)
Storage Temperature 5 °F to 113 °F (-15 °C to 45 °C)
Environmental RoHS Compliant
Safety UL1778, cUL107.1, FCC Class B
Connected Equipment Guarantee Lifetime
Product Warranty 3 Years Limited
