Output | ||
Output power capacity | 2.7 KWatts / 3.0 kVA | |
Max Configurable Power (Watts) | 2.7 KWatts / 3.0 kVA | |
Nominal Output Voltage | 120V | |
Output Voltage Distortion | Less than 2% | |
Output Frequency (sync to mains) | 50/60Hz +/- 3 Hz | |
Load Crest Factor | 3 : 1 | |
Topology | Double Conversion Online | |
Waveform type | Sine wave | |
Output Connections |
(8) NEMA 5-20R (Battery Backup)
(1) NEMA L5-30R (Battery Backup) |
|
Bypass | Internal Bypass (Automatic and Manual) | |
Input | ||
Nominal Input Voltage | 120V | |
Input frequency | 40 - 70 Hz (auto sensing) | |
Input Connections | NEMA L5-30P | |
Cord Length | 8ft ( 2.44meters ) | |
Number of Power Cords | 1 | |
Batteries & Runtime | ||
Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof | |
Included Battery Modules | 1 | |
Typical recharge time | 3hour(s) | |
Replacement Battery | APCRBC152 | |
Expected Battery Life (years) | 3 - 5 | |
RBC Quantity | 1 | |
Extendable Run Time | 1 | |
Extended Run Options | APC-Smart-UPS-SRT-3000VA-RM-120V-Network-Card | |
Efficiency | View Efficiency Graph | |
Communications & Management | ||
Interface Port(s) | RJ-45 10/100 Base-T , RJ-45 Serial , Smart-Slot , USB | |
Pre-Installed SmartSlot™ Cards | AP9631 | |
Control panel | Multi-function LCD status and control console | |
Audible Alarm | Audible and visible alarms prioritized by severity | |
Emergency Power Off (EPO) | Yes | |
Surge Protection and Filtering | ||
Surge energy rating | 340Joules | |
Filtering | -- | |
Physical | ||
Maximum Height | 3.35inches ( 85mm , 8.5CM ) | |
Maximum Width | 17.0inches ( 432mm , 43.2CM ) | |
Maximum Depth | 25.0inches ( 635mm , 63.5CM ) | |
Rack Height | 2U | |
Net Weight | 69.0lbs. ( 31.3KG ) | |
Shipping weight | 88.0lbs. ( 39.92KG ) | |
Shipping Height | 9.7inches ( 246mm , 24.6CM ) | |
Shipping Width | 23.6inches ( 599mm , 59.9CM ) | |
Shipping Depth | 34.3inches ( 871mm , 87.1CM ) | |
Color | Black | |
Units per Pallet | 6.0 | |
Environmental | ||
Operating Temperature | 32 - 104 °F ( 0 - 40 °C ) | |
Operating Relative Humidity | 0 - 95% non-condensing % | |
Operating Elevation | 0-10000ft ( 0-3000meters ) | |
Storage Temperature | -15 - 45 °C | |
Storage Relative Humidity | 0 - 95% non-condensing % | |
Storage Elevation | 0-50000ft ( 0-15000meters ) | |
Audible noise at 1 meter from surface of unit | 55.0dBA | |
Online thermal dissipation | 805.0BTU/hr | |
Protection Class | IP 20 | |
Conformance | ||
Approvals | CSA C22.2 No.107.3-05, ENERGY STAR V1.0 (USA), FCC Part 15 Class A, OSHPD, UL 1778 | |
Standard warranty | 3 years repair or replace (excluding battery) and 2 years for battery | |
Sustainable Offer Status | ||
RoHS | Compliant | |
REACH | REACH: Contains No SVHCs |
