Smart White, 80 PLUS Standard 700W, No Modular, ATX Power Supply

Quantity:
  • SKU: 10013140
  • Manufacturer: THERMALTAKE
  • MPN: PS-SPD-0700NPCWUS-W
  • Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$72.17
Quantity:
P/N

PS-SPD-0700NPCW**-W

Short P/N

SPD-0700P

Model

SP-700AH2NKW

Type

Intel ATX 12V 2.3

Max. Output Capacity

700W

Color

Black

Dimension (H x W x D)

86mm x 150mm x 140mm

PFC (Power Factor Correction)

Active PFC

Power Good Signal

100-500 msec

Hold Up Time

16msec (minimum) within 60% load

Input current

12A max

Input Frequency Range

50 Hz - 60 Hz

Input Voltage

100Vac - 240Vac

Operating Temperature 5° to +40°
Operating Humidity 20% to 85%,non-condensing
Operating Temperature

-40° to +55°

Operating Humidity

10% to 95%, non-condensing

Cooling System 120mm Fan: 1800 R.P.M. ± 10%
Efficiency

80-87% efficiency @ 20-100% load

MTBF

100,000 hrs minimum

Safety Approval

CE/CB/TUV/ UL/ FCC

PCI-E Connector

PCI-E 6+2pin x 2

AC INPUT Input Voltage: 100V - 240V
Input Current: 12A max
Frequency: 50Hz - 60Hz
DC OUTPUT +3.3V +5V +12V -12V +5Vsb
Max Output Current 24A 17A 54A 0.5A 2.5A
Max Output Power 120W 648W 6.0W 12.5W
Continuous Power 700W
