Straight Power 12, 80 PLUS Platinum 1500W, Fully Modular, ATX Power Supply

Quantity:
  • SKU: 16427148
  • Manufacturer: be quiet!
  • MPN: BN518
  • Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$392.72
Quantity:
Straight Power 12, 80 PLUS Platinum 1500W, Fully Modular, ATX Power Supply

THE NEW STANDARD OF POWER
For massive transient loads

Straight Power 12 offers 1500W of continuous power with one massive 12V rail. Even if the graphics card demands excessive power for a short time: Straight Power 12 1500W handles power excursions up to double its rated power with ease. This ensures reliable operation with the next generation of processors and graphics cards.

  • 80 PLUS Platinum efficiency (up to 93.9%)
  • ATX 3.0 PSU with full support for PCIe 5.0 GPUs and GPUs with 6+2 pin connectors
  • Handles massive power excursions
  • Virtually inaudible Silent Wings 135mm fan
  • Funnel-shaped fan opening on PSU case for high airflow intake
  • Full bridge LLC technology for unmatched signal stability
  • One massive high-performance 12V-rail
  • Japanese 105°C capacitors ensure highest stability and reliability
  • Modular cable management for maximum convenience
  • 10-year manufacturer’s warranty
General data
Model Straight Power 12 1500W
Continuous power (W) 1500
Peak power (W) 1570
Form factor Version 3.0
Form factor EPS 12V Version 2.92
Topology Full bridge + LLC + SR + DC/DC
Digitally controlled -
Voltage ( Vac ) 110 - 240
Frequency ( Hz ) 50 - 60
Input current (A) 15/ 9
Power factor at 100% load >0.99
Modern standby
Power consumption in standby (W) 0.15
Average life time (h / 25°C) >100,000
Operating temperature up to (°C) 40
Efficiency
80 PLUS certification Platinum
Efficiency (%) at 230V, 2% load 65.0
Efficiency (%) at 230V, 10% load 90.5
Efficiency (%) at 230V, 20% load 93.1
Efficiency (%) at 230V, 50% load 93.9
Efficiency (%) at 230V, 100% load 91.9
Fan and cooling technology
Fan Silent Wings
Fan size (mm) 135
Bearing technology FDB
Motor technology 6-pole fan motor
Max. fan speed (rpm) 2600
dB(A) at 10% load 9
dB(A) at 20% load 9
dB(A) at 50% load 12.7
dB(A) at 100% load 36.4
Output
Multi-rail operation ( 12V rails ) -
12V single rail operation
Overclocking key -
+3.3V (A) 25
+5V (A) 25
+12V1 (A) 125
+12V2 (A) -
+12V3 (A) -
+12V4 (A) -
+12V5 (A) -
+12V6 (A) -
-12V (A) 0.5
+5Vsb (A) 3
Max. combined power 12V (W) 1500
Max. combined power 12VHPWR (W) 1000
Max. combined power 3.3V + 5V (W) 150
Hold-up time at 100% load (ms) 20.6
Power good signal (ms) 100 - 150
Cables and connectors
Modular cables
Sleeved cables
Flat cables -
Maximum cable length (cm) 100
Cable length to motherboard (cm) 60
No. of cables 10
ATX -Motherboard ( 20+4-pin ) 1
P4 +4 (CPU) 1
P8 (CPU) 1
P4 (CPU) -
12VHPWR cables 2
PCI-e 6+2-pin ( GPU ) 4
PCI-e 6-pin ( GPU ) -
SATA 9
PATA 2
FDD (Floppy) -
Protection
OTP (over temperature protection)
OCP (over current protection)
OPP (over power protection)
SCP (short circuit protection)
OVP (over Voltage protection)
UVP (under Voltage protection)
SIP (Surge & Inrush Protection)
Safety certification
BSMI
CB
CCC
CE
cRUus -
cTUVus
CU
FCC
RCM
TÜV
UKCA
Environmental directives
Energy Star 8.0
ErP
WEEE
RoHS
Triman
Scope of delivery
Thumb screws -
Screws
Cable ties
Velcro cable ties -
User manual languages CN, DE, EN, ES, FR, JP, PL, RU, TW, KR
OCK slot bracket with switch / OCK jumper -
SFX -to- ATX adapter bracket -
Casing
Dimensions without cable (L x W x H), (mm) 180 x 150 x 86
Weight (kg) 2.12
Color Black
Service
Warranty (Years) 10
Express replacement service in first year DE, FR
International hotline / free of charge ✓ / DE, FR
Logistics data and RRP
Article number BN518
EAN code 4260052189641
Dimensions, package (L x W x H), (mm) 328 x 248 x 102
Gross weight, package (kg) 3.97
