TC-2U70PD8, 700W, 2U, High Efficiency Switching, Power Supply
Quantity:
- SKU: 6349557
- Manufacturer: ISTARUSA
- MPN: TC-2U70PD8
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$192.05
TC-2U70PD8, 700W, 2U, High Efficiency Switching, Power Supply
XEAL 2U power supply series provide high performance in compact form factor. The TC-2U70PD8 supports server, compact PC, and space constrained application. Standard feature includes high efficiency, triple circuits protection, and EPS 2U for industrial and high performance system requirement.
- High Efficiency 82% minimum
- Universal Power Input
- Over Current Protection
- Over Voltage Protectio
- Over Power Protection
- Short Circuit Protection
| Model Number | TC-2U70PD8 |
| RoHS Compliance Version | Yes |
| Output Wattage | 700 |
| Efficiency | 82% |
| Connector Type | Main Connector :: 20+4 pin 4+4pin 12V :: 1 8pin EPS 12V :: 1 6+2 Pin PCIE :: 2 Molex :: 5 SATA :: 4 Floppy :: 1 |
| Dimensions (WxHxD) | 3.94" x 2.76" x 10.24" 100.1 mm x 70.1 mm x 260.1 mm |
