TR200 WS, Mesh Panel, LCD, No PSU, microATX, Snow, Mini Tower Case
- SKU: 20216545
- Manufacturer: THERMALTAKE
- MPN: CA-11L-00S6NN-W1
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
TR200 WS, Mesh Panel, LCD, No PSU, microATX, Snow, Mini Tower Case
Designed to perform as a compact mid tower while still offering plenty of space to build the TR300 WS merges a small footprint with a full-size PC. In terms of space the TR300 can fit ATX/mATX/mITX motherboards, 410mm GPUs, 360mm radiators, and up to eight 120mm fans. For an extra upgrade there is the 6.0 inch LCD Screen Kit preinstalled for custom pictures, GIF, and even real-time system info.
Designed to perform as a compact mid tower while still offering plenty of space to build the TR300 WS merges a small footprint with a full-size PC. In terms of space the TR300 can fit ATX/mATX/mITX motherboards, 410mm GPUs, 360mm radiators, and up to eight 120mm fans. For an extra upgrade there is the 6.0 inch LCD Screen Kit preinstalled for custom pictures, GIF, and even real-time system info.
| P/N | CA-11L-00S6NN-W1 |
| Series | TR Series |
| Case Type | Micro Case |
| Dimensions | 364 x 220 x 494 mm (14.33 x 8.66 x 19.45 inch) |
| Side Panel | Steel |
| Color | Snow |
| Material | SPCC |
| Cooling System | Rear(exhaust): 120 x 120 x 25 mm Standard fan (1400rpm, 23.2 dBA) x 1 |
| Expansion Slots | 5 |
| Motherboard | 6.7" x 6.7" (Mini ITX), 9.6" x 9.6" (Micro ATX) |
| I/O Port | USB 3.1 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| Fan Support |
Top: 3 x 120mm, 2x 120mm ,1x 120mm 2 x 140mm, 1 x 140mm Rear: 1 x 120mm Bottom: 3x 120mm, 2x 120mm, 1x 120mm |
| Radiator Support |
Top(AIO) : 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm Rear(AIO) : 1 x 120mm |
| Clearance |
CPU cooler height limitation: 175mm VGA length limitation: 365mm PSU length limitation: 258mm |
