| P/N |
PS-TPD-0850FNFAGU-W |
| WATTS |
850W |
| MODEL |
TTP-850AH3FCG |
| MAX. OUTPUT CAPACITY |
850W |
| PEAK OUTPUT CAPACITY |
1020W |
| COLOR |
White |
| DIMENSION ( W / H / D ) |
150mm(W) x 86mm(H) x 160mm(D) |
| PFC (POWER FACTOR CORRECTION) |
Active PFC |
| POWER GOOD SIGNAL |
100-500 msec |
| HOLD UP TIME |
> 16msec at 100% of full load |
| INPUT CURRENT |
12A |
| INPUT FREQUENCY RANGE |
47Hz - 63Hz |
| INPUT VOLTAGE |
100V – 240V~ |
| OPERATING TEMPERATURE |
0°C to + 50°C |
| OPERATING HUMIDITY |
20% to 90%,non-condensing |
| STORAGE TEMPERATURE |
-20°C to + 70°C |
| STORAGE HUMIDITY |
5% to 95%, non-condensing |
| COOLING SYSTEM |
14cm hydraulic bearing fan |
| EFFICIENCY |
Meet 80 PLUS®Gold at 115Vac input. |
| MTBF |
120,000 hrs minimum |
| SAFETY APPROVAL |
CE/cTUVus/TÜV/FCC/BSMI/CCC/EAC |
| PCI-E 6+2PIN |
6 |
| PROTECTION |
OCP, OVP, UVP, OPP, SCP, OTP |
