Toughpower GF3, 80 PLUS Gold 1000W, PCIe 5.0, Fully Modular, ATX Power Supply
- SKU: 15143174
- Manufacturer: THERMALTAKE
- MPN: PS-TPD-1000FNFAGU-4
- Availability: TEMPORARILY OUT OF STOCK
Price
$208.16
Toughpower GF3, 80 PLUS Gold 1000W, PCIe 5.0, Fully Modular, ATX Power Supply
Designed with a native PCIe 12+4pin connector, the Toughpower GF3 series (TPD-1000AH3FCG) is compatible with Intel ‘s ATX 3.0 specification and is built for next-gen PCIe 5.0 graphics cards.
Designed with a native PCIe 12+4pin connector, the Toughpower GF3 series (TPD-1000AH3FCG) is compatible with Intel ‘s ATX 3.0 specification and is built for next-gen PCIe 5.0 graphics cards.
| P/N | PS-TPD-1000FNFAGU-4 |
| WATTS | 1000W |
| MODEL | TPD-1000AH3FCG |
| MAX. OUTPUT CAPACITY | 1000W |
| COLOR | Black |
| DIMENSION ( W / H / D ) | 150mm(W) x 86mm(H) x 160mm(D) |
| WEIGHT | 1.72 KG |
| PFC (POWER FACTOR CORRECTION) | Active PFC |
| POWER GOOD SIGNAL | 100-150 msec |
| HOLD UP TIME | > 17msec at 100% of full load |
| INPUT CURRENT | 13.0A / 6.5A |
| INPUT FREQUENCY RANGE | 50/60Hz |
| INPUT VOLTAGE | 100V – 240V~ |
| OPERATING TEMPERATURE | 0°C to + 40°C |
| OPERATING HUMIDITY | 20% to 90%,non-condensing |
| STORAGE TEMPERATURE | -20°C to + 70°C |
| STORAGE HUMIDITY | 5% to 95%, non-condensing |
| COOLING SYSTEM | 13.5cm fluid bearing fan |
| EFFICIENCY | Meet 80 PLUS®Gold at 115Vac input. |
| MTBF | 100,000 hrs minimum |
| SAFETY APPROVAL | CE/UKCA/cTUVus/TÜV/FCC/IC/BSMI/EAC/CB/CCC |
| PROTECTION | OCP, OVP, UVP, OPP, SCP, OTP |
| PCI-E CONNECTOR |
PCIe 6+2pin x 4 PCIe 12+4pin x 1 |
