MODEL | UNI FAN SL140 |
FAN DIMENSION | 140 X 140 X25 ( mm ) |
RATED VOLTAGE | DC 12V(FAN) & 5V(LED) |
FAN SPEED | 500~1500RPM |
MAX. AIR PRESSURE | 1.67mmH2O |
MAX. AIR FLOW | 70.5 CFM |
ACOUSTICAL NOISE (MIN-MAX.) | 30dB(A) Max |
LOCKED CURRENT | >= 10mA |
BEARING TYPE | Fluid Dynamic Bearing(FDB) |
START-UP VOLTAGE | DC 6.0V |
INPUT CURRENT | 100mA(FAN) / 340mA (LED) |
INPUT POWER | 3.6W |
WARRANTY | 2 year |
