|Material||Side Panel:SPCC t:0.8mm
Horizontal Rails:SPCC t:2.0mm
Vertical Rails:SPCC t:2.0mm
Top Panel:SPCC t:1.2mm
|Loading Capacity||static loading w/o casters:2200lbs/ static loading with casters:880lbs/ dynamic loading:660lbs|
|Supported Chassis Depth||34" and under|
|Internal Dimensions||Height: 27.25"
Depth: outer post-to-post 34.25" max
|Cooling||Up to 3 sets of 120mm 120V AC fans can be installed on the top (p/n: WA-SF120-2FAN) Pre-installed 1 set|
|Dimensions (WxHxD)||23.50" x 35.25" x 39.50"
597 mm x 895 mm x 1,003 mm
|Notes||- for HP/ DELL/ IBM servers equipped with sliding rails, please contact sales person for availability of model number WN1510-EX.
- HTS code: 8473.30.5100 (ECCN is not applicable).
