- 5 x Ø6mm heat-pipe with aluminum fins for excellent heat conducting efficiency
- High reliability with dual ball bearing, PWM controlled fan
- Compatible with Intel LGA4677/4710 socket
Model No. | SST-XE04-4677 (Silver+Black) SST-XE04-4677B (Black+Black) |
Material | Copper heat pipes with aluminum fins |
Application | Intel LGA4677/LGA4710 (CPU Carrier not included) |
Fan | |
Dimension |
92mm (W) x 25mm (H) x 92mm (D) 3.62" (W) x 0.98" (H) x 3.62" (D) |
Speed | 1500 ~ 5000 RPM |
Noise level | 43 dBA |
Rated Voltage | 12V |
Rated Current | 0.66A |
Max airflow | 77.7 CFM |
Max air pressure | 10.67mm H2O |
Connector | 4 pin PWM |
Bearing | Dual ball bearing |
MTTF | 90,000 hours |
CPU TDP | 270W |
Dimension |
93mm (W) x 126mm (H) x 118mm (D) 3.66" (W) x 4.96" (H) x 4.65" (D) |
Net weight | 795g |
