| Essentials |
| Product Collection |
Intel® Xeon® E Processor |
| Code Name |
Products formerly Coffee Lake |
| MPN |
CM8068403654114 |
| Vertical Segment |
Server |
| Processor Number |
E-2124G |
| Status |
Launched |
| Launch Date |
Q3'18 |
| Lithography |
14 nm |
| Use Conditions |
Embedded Broad Market Commercial Temp, PC/Client/Tablet |
| Performance |
| # of Cores |
4 |
| # of Threads |
4 |
| Processor Base Frequency |
3.40 GHz |
| Max Turbo Frequency |
4.50 GHz |
| Cache |
8 MB SmartCache |
| Bus Speed |
8 GT/s DMI3 |
| TDP |
71 W |
| Supplemental Information |
| Embedded Options Available |
Yes |
| Datasheet |
View now |
| Memory Specifications |
| Max Memory Size (dependent on memory type) |
128 GB |
| Memory Types |
DDR4-2666 |
| Max # of Memory Channels |
2 |
| Max Memory Bandwidth |
41.6 GB/s |
| ECC Memory Supported |
Yes |
| Processor Graphics |
| Processor Graphics |
Intel® UHD Graphics P630 |
| Graphics Base Frequency |
350 MHz |
| Graphics Max Dynamic Frequency |
1.15 GHz |
| Graphics Video Max Memory |
128 GB |
| Graphics Output |
eDP/DP/HDMI/DVI |
| 4K Support |
Yes, at 60Hz |
| Max Resolution (HDMI 1.4) |
4096x2160@24Hz |
| Max Resolution (DP) |
4096x2304@60Hz |
| Max Resolution (eDP - Integrated Flat Panel) |
4096x2304@60Hz |
| Max Resolution (VGA) |
N/A |
| DirectX* Support |
12 |
| OpenGL* Support |
4.5 |
| Intel® Quick Sync Video |
Yes |
| Intel® InTru™ 3D Technology |
Yes |
| Intel® Clear Video HD Technology |
Yes |
| Intel® Clear Video Technology |
Yes |
| # of Displays Supported |
3 |
| Device ID |
0x3E96 |
| Expansion Options |
| Scalability |
1S Only |
| PCI Express Revision |
3.0 |
| PCI Express Configurations |
1x16,2x8,1x8+2x4 |
| Max # of PCI Express Lanes |
16 |
| Package Specifications |
| Sockets Supported |
FCLGA1151 |
| Max CPU Configuration |
1 |
| Package Size |
37.5mm x 37.5mm |
| Low Halogen Options Available |
See MDDS |
| Advanced Technologies |
| Intel® Optane™ Memory Supported |
Yes |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® vPro™ Technology |
Yes |
| Intel® Hyper-Threading Technology |
No |
| Intel® Virtualization Technology (VT-x) |
Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel® VT-x with Extended Page Tables (EPT) |
Yes |
| Intel® TSX-NI |
Yes |
| Intel® 64 |
Yes |
| Instruction Set |
64-bit |
| Instruction Set Extensions |
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States |
Yes |
| Enhanced Intel SpeedStep® Technology |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Security & Reliability |
| Intel® AES New Instructions |
Yes |
| Secure Key |
Yes |
| Intel® Software Guard Extensions (Intel® SGX) |
Yes with Intel® ME |
| Intel® Memory Protection Extensions (Intel® MPX) |
Yes |
| Intel® OS Guard |
Yes |
| Intel® Trusted Execution Technology |
Yes |
| Execute Disable Bit |
Yes |
| Intel® Boot Guard |
Yes |
