Xeon® E-2336 6-Core 2.9 - 4.8GHz Turbo, LGA 1200, 65W TDP, OEM Processor

Quantity:
  • SKU: 14675013
  • Manufacturer: INTEL
  • MPN: CM8070804495816
  • Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$362.19
Quantity:
Essentials
Product Collection Intel® Xeon® E Processor
Code Name Products formerly Rocket Lake
Vertical Segment Server
Processor Number E-2336
Lithography 14 nm
Use Conditions Server/Enterprise
CPU Specifications
Total Cores 6
Total Threads 12
Max Turbo Frequency 4.80 GHz
Intel® Turbo Boost Technology 2.0 Frequency‡ 4.80 GHz
Processor Base Frequency 2.90 GHz
Cache 12 MB Intel® Smart Cache
Bus Speed 8 GT/s
TDP 65 W
Supplemental Information
Marketing Status Launched
Launch Date Q3'21
Servicing Status Baseline Servicing
Embedded Options Available No
Memory Specifications
Max Memory Size (dependent on memory type) 128 GB
Memory Types DDR4-3200
Max # of Memory Channels 2
Intel® Optane™ Persistent Memory Supported No
ECC Memory Supported   Yes
Expansion Options
Scalability 1S Only
PCI Express Revision 4.0
Microprocessor PCIe Revision Gen 4
PCI Express Configurations Up to 1x16+1x4 |  2x8+1x4 |  1x8+3x4
Max # of PCI Express Lanes 20
Package Specifications
Sockets Supported FCLGA1200
Max CPU Configuration 1
TJUNCTION 100 °C
Package Size 37.5 mm x 37.5 mm
Advanced Technologies
Intel® Turbo Boost Technology 2.0
Intel® Hyper-Threading Technology Yes
Intel® Transactional Synchronization Extensions No
Intel® 64 Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2 |  Intel® AVX-512
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Security & Reliability
Intel vPro® Eligibility Intel vPro® Platform
Intel® AES New Instructions Yes
Secure Key Yes
Intel® Software Guard Extensions (Intel® SGX) Yes with Intel® SPS
Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX 0.5 GB
Intel® Memory Protection Extensions (Intel® MPX) Yes
Intel® OS Guard Yes
Intel® Trusted Execution Technology Yes
Execute Disable Bit Yes
Intel® Boot Guard Yes
Intel® Virtualization Technology (VT-x) Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel® VT-x with Extended Page Tables (EPT) Yes
