Xeon® E-2336 6-Core 2.9 - 4.8GHz Turbo, LGA 1200, 65W TDP, Retail Processor
Quantity:
- SKU: 14721179
- Manufacturer: INTEL
- MPN: BX80708E2336
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$376.34
| Essentials | |
| Product Collection | Intel® Xeon® E Processor |
| Code Name | Products formerly Rocket Lake |
| Vertical Segment | Server |
| Processor Number | E-2336 |
| Status | Launched |
| Launch Date | Q3'21 |
| Lithography | 14 nm |
| Use Condition | Server/Enterprise |
| CPU Specifications | |
| Total Cores | 6 |
| Total Threads | 12 |
| Max Turbo Frequency | 4.80 GHz |
| Intel® Turbo Boost Technology 2.0 Frequency | 4.80 GHz |
| Processor Base Frequency | 2.90 GHz |
| Cache | 12 MB Intel® Smart Cache |
| Bus Speed | 8 GT/s |
| TDP | 65 W |
| Supplemental Information | |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 128 GB |
| Memory Types | DDR4-3200 |
| Max # of Memory Channels | 2 |
| ECC Memory Supported | Yes |
| Intel® Optane™ Persistent Memory Supported | No |
| Expansion Options | |
| Scalability | 1S Only |
| PCI Express Revision | 4.0 |
| Microprocessor PCIe Revision | Gen 4 |
| PCI Express Configurations | Up to 1x16+1x4, 2x8+1x4, 1x8+3x4 |
| Max # of PCI Express Lanes | 20 |
| Package Specifications | |
| Sockets Supported | FCLGA1200 |
| Max CPU Configuration | 1 |
| TJUNCTION | 100 °C |
| Package Size | 37.5 mm x 37.5 mm |
| Advanced Technologies | |
| Intel® Turbo Boost Technology | 2.0 |
| Intel vPro® Platform Eligibility | Yes |
| Intel® Hyper-Threading Technology | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Transactional Synchronization Extensions | No |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2, Intel® AVX-512 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Security & Reliability | |
| Intel® AES New Instructions | Yes |
| Secure Key | Yes |
| Intel® Software Guard Extensions (Intel® SGX) | Yes with Intel® SPS |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Intel® OS Guard | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® Boot Guard | Yes |
| Maximum Enclave Page Cache (EPC) Size for Intel® SGX | 0.5 GB |
