Xeon® Gold 5220T 18-Core 1.9 - 3.9GHz Turbo, LGA 3647, 2 UPI, 105W, OEM Processor

Quantity:
  • SKU: 12764622
  • Manufacturer: INTEL
  • MPN: CD8069504283006
  • Availability: TEMPORARILY OUT OF STOCK
Starting At
$2,156.57
Quantity:
Essentials
Product Collection 2nd Generation Intel® Xeon® Scalable Processors
Code Name Products formerly Cascade Lake
Vertical Segment Server
Processor Number 5220T
Status Launched
Launch Date Q2'19
Lithography 14 nm
Performance
# of Cores 18
# of Threads 36
Processor Base Frequency 1.90 GHz
Max Turbo Frequency 3.90 GHz
Cache 25 MB
# of UPI Links 2
TDP 105 W
Supplemental Information
Embedded Options Available Yes
Memory Specifications
Max Memory Size (dependent on memory type) 1 TB
Memory Types DDR4-2667
Maximum Memory Speed 2667 MHz
Max # of Memory Channels 6
ECC Memory Supported Yes
Intel® Optane™ DC Persistent Memory Supported Yes
Expansion Options
Scalability 4S
PCI Express Revision 3.0
Max # of PCI Express Lanes 48
Package Specifications
TCASE 93°C
Package Size 76.0mm x 56.5mm
Advanced Technologies
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Speed Select technology - Performance Profile No
Intel® Speed Select technology - Base Frequency No
Intel® Resource Director Technology (Intel® RDT) Yes
Intel® Speed Shift Technology Yes
Intel® Turbo Boost Max Technology 3.0 No
Intel® Turbo Boost Technology 2.0
Intel® vPro™ Platform Eligibility Yes
Intel® Hyper-Threading Technology Yes
Intel® Virtualization Technology (VT-x) Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel® VT-x with Extended Page Tables (EPT) Yes
Intel® TSX-NI Yes
Intel® 64 Yes
Instruction Set Extensions Intel® AVX-512
# of AVX-512 FMA Units 1
Enhanced Intel SpeedStep® Technology Yes
Intel® Volume Management Device (VMD) Yes
Security & Reliability
Intel® AES New Instructions Yes
Intel® Trusted Execution Technology Yes
Execute Disable Bit Yes
Intel® Run Sure Technology Yes
Mode-based Execute Control (MBE) Yes
