Xeon® Gold 6230T 20-Core 2.1 - 3.9GHz Turbo, LGA 3647, 3 UPI, 125W, OEM Processor

  • SKU: 12764679
  • Manufacturer: INTEL
  • MPN: CD8069504283704
Starting At
Product Collection 2nd Generation Intel® Xeon® Scalable Processors
Code Name Products formerly Cascade Lake
Vertical Segment Server
Processor Number 6230T
Status Launched
Launch Date Q2'19
Lithography 14 nm
# of Cores 20
# of Threads 40
Processor Base Frequency 2.10 GHz
Max Turbo Frequency 3.90 GHz
Cache 28 MB
# of UPI Links 3
TDP 125 W
Supplemental Information
Embedded Options Available Yes
Memory Specifications
Max Memory Size (dependent on memory type) 1 TB
Memory Types DDR4-2933
Maximum Memory Speed 2933 MHz
Max # of Memory Channels 6
ECC Memory Supported Yes
Intel® Optane™ DC Persistent Memory Supported Yes
Expansion Options
Scalability 4S
PCI Express Revision 3.0
Max # of PCI Express Lanes 48
Package Specifications
Package Size 76.0mm x 56.5mm
Advanced Technologies
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Speed Select technology - Performance Profile No
Intel® Speed Select technology - Base Frequency No
Intel® Resource Director Technology (Intel® RDT) Yes
Intel® Speed Shift Technology Yes
Intel® Turbo Boost Max Technology 3.0 No
Intel® Turbo Boost Technology 2.0
Intel® vPro™ Platform Eligibility Yes
Intel® Hyper-Threading Technology Yes
Intel® Virtualization Technology (VT-x) Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel® VT-x with Extended Page Tables (EPT) Yes
Intel® TSX-NI Yes
Intel® 64 Yes
Instruction Set Extensions Intel® AVX-512
# of AVX-512 FMA Units 2
Enhanced Intel SpeedStep® Technology Yes
Intel® Volume Management Device (VMD) Yes
Security & Reliability
Intel® AES New Instructions Yes
Intel® Trusted Execution Technology Yes
Execute Disable Bit Yes
Intel® Run Sure Technology Yes
Mode-based Execute Control (MBE) Yes
