Xeon® Platinum 8276M 28-Core 2.2 - 4.0GHz Turbo, LGA 3647, 3 UPI, 165W, OEM Processor
Quantity:
- SKU: 12690016
- Manufacturer: INTEL
- MPN: CD8069504195401
- Availability: TEMPORARILY OUT OF STOCK
Starting At
$12,926.56
| Essentials | |
|---|---|
| Product Collection | 2nd Generation Intel® Xeon® Scalable Processors |
| Code Name | Products formerly Cascade Lake |
| Vertical Segment | Server |
| Processor Number | 8276M |
| Status | Launched |
| Launch Date | Q2'19 |
| Lithography | 14 nm |
| Performance | |
| # of Cores | 28 |
| # of Threads | 56 |
| Processor Base Frequency | 2.20 GHz |
| Max Turbo Frequency | 4.00 GHz |
| Cache | 39 MB |
| # of UPI Links | 3 |
| TDP | 165 W |
| Supplemental Information | |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 2 TB |
| Memory Types | DDR4-2933 |
| Maximum Memory Speed | 2933 MHz |
| Max # of Memory Channels | 6 |
| ECC Memory Supported | Yes |
| Expansion Options | |
| Scalability | S8S |
| PCI Express Revision | 3.0 |
| Max # of PCI Express Lanes | 48 |
| Package Specifications | |
| Sockets Supported | FCLGA3647 |
| TCASE | 89°C |
| Package Size | 76.0mm x 56.5mm |
| Advanced Technologies | |
| Intel® Optane™ Memory Supported | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Max Technology 3.0 | No |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Hyper-Threading Technology | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Intel® TSX-NI | Yes |
| Intel® 64 | Yes |
| Instruction Set Extensions | Intel® AVX-512 |
| # of AVX-512 FMA Units | 2 |
| Enhanced Intel SpeedStep® Technology | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Security & Reliability | |
| Intel® AES New Instructions | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® Run Sure Technology | Yes |
| Mode-based Execute Control (MBE) | Yes |
