Essentials |
Product Collection |
2nd Generation Intel® Xeon® Scalable Processors |
Code Name |
Products formerly Cascade Lake |
Vertical Segment |
Server |
Processor Number |
4210R |
Off Roadmap |
No |
Status |
Launched |
Launch Date |
Q1'20 |
Lithography |
14 nm |
Performance |
# of Cores |
10 |
# of Threads |
20 |
Processor Base Frequency |
2.40 GHz |
Max Turbo Frequency |
3.20 GHz |
Cache |
13.75 MB |
# of UPI Links |
2 |
TDP |
100 W |
Supplemental Information |
Embedded Options Available |
Yes |
Memory Specifications |
Max Memory Size (dependent on memory type) |
1 TB |
Memory Types |
DDR4-2400 |
Maximum Memory Speed |
2400 MHz |
Max # of Memory Channels |
6 |
ECC Memory Supported ‡ |
Yes |
Intel® Optane™ DC Persistent Memory Supported |
No |
Expansion Options |
Scalability |
2S |
PCI Express Revision |
3.0 |
Max # of PCI Express Lanes |
48 |
Package Specifications |
Sockets Supported |
FCLGA3647 |
TCASE |
84°C |
Package Size |
76.0mm x 56.5mm |
Advanced Technologies |
Intel® Deep Learning Boost (Intel® DL Boost) |
Yes |
Intel® Speed Select Technology - Performance Profile |
No |
Intel® Speed Select Technology - Base Frequency |
No |
Intel® Resource Director Technology (Intel® RDT) |
Yes |
Intel® Speed Shift Technology |
Yes |
Intel® Turbo Boost Max Technology 3.0 ‡ |
No |
Intel® Turbo Boost Technology ‡ |
2.0 |
Intel® vPro™ Platform Eligibility ‡ |
Yes |
Intel® Hyper-Threading Technology ‡ |
Yes |
Intel® Virtualization Technology (VT-x) ‡ |
Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ |
Yes |
Intel® VT-x with Extended Page Tables (EPT) ‡ |
Yes |
Intel® Transactional Synchronization Extensions |
Yes |
Intel® 64 ‡ |
Yes |
Instruction Set Extensions |
Intel® SSE4.2, Intel® AVX, Intel® AVX2, Intel® AVX-512 |
# of AVX-512 FMA Units |
1 |
Enhanced Intel SpeedStep® Technology |
Yes |
Intel® Volume Management Device (VMD) |
Yes |
Security & Reliability |
Intel® AES New Instructions |
Yes |
Intel® Trusted Execution Technology ‡ |
Yes |
Execute Disable Bit ‡ |
Yes |
Intel® Run Sure Technology |
No |
Mode-based Execute Control (MBE) |
Yes |
