| Specifications |
| Expansion slot |
7 |
| 2.5" drive mounts |
2 |
| 3.5" drive mounts |
2 |
| Tool-less push-to-lock |
Left/Right side, top and front panels |
| Front I/O ports |
2 x USB 3.0 Type-A, 1 x USB 3.2 Gen 2 Type-C, 1 x 3.5mm audio & mic combo |
| Top I/O ports |
1 x power button, 4 x LED control bottom |
| Fan support |
Bottom: 3 x 120mm, Rear: 3 x 120mm, Side: 1 x 120mm, Top: 3 x 120mm with 2nd Slot GPU |
| Dust filters |
Bottom, Rear, Side |
| Panels |
2 x tempered glass, 1 x steel, 1 x plastic |
| Compatibility |
| Motherboard compatibility |
ATX / Micro-ATX / Mini-ITX |
| Power supply type |
ATX / SFX (ATX adapter bracket required) |
| Power supply max length |
190mm |
| CPU cooler max height |
170mm |
| GPU max length |
370mm length and 160mm width |
| Radiator support |
Bottom: 1 x 120/240/360mm, Rear: 1 x 120/240/360mm |
| General |
| Case dimensions |
417 x 237 x 508 mm / 16.4 x 9.3 x 20 inch |
| Case dimensions (w/o feet) |
417 x 237 x 493 mm / 16.4 x 9.3 x 19.4 inch |
| Package dimensions |
565 x 309 x 495 mm / 22.24 x 12.17 x 19.17 inch |
| Net weight |
10.5 Kg / 23.2 lb |
| Gross weight |
13.7 Kg / 30.2 lb |
| Volume |
50 liters |
| Package contents |
Case, accessory box, user manual |
| Warranty |
2 years |
| User Guide |
Xhuttle User Guide |
