One cable is all you need
ZenScreen MB166C uses a single USB Type-C connection for both power and video transmission from your host device. This means you have less cables to work with, so you get a neater work area.
Display |
Panel Size (inch) : 15.6 Aspect Ratio : 16:9 Display Viewing Area (H x V) : 344.16 x 193.59mm Display Surface : Non-Glare Backlight Type : LED Panel Type : IPS Viewing Angle (CR ≧10, H/V) : 178°/ 178° Pixel Pitch : 0.179mm Resolution : 1920x1080 Brightness (Typ.) : 250cd/m2 Contrast Ratio (Typ.) : 800:1 Display Colors : 262K Response Time : 5ms(GTG) Refresh Rate (Max) : 60Hz Flicker-free : Yes |
Video Feature |
Trace Free Technology : Yes SPLENDID Technology : Yes Color Temp. Selection : Yes(4 modes) GamePlus : Yes QuickFit : Yes (Photo/Alighment Grid) HDCP : Yes, 1.4 DisplayWidget : Yes Low Blue Light : Yes |
Audio Feature | Speaker : No |
I/O Ports | USB-C x 1 |
Signal Frequency | Digital Signal Frequency : USB-C: 24-83KHZ (H) / 60Hz(V |
Power Consumption |
Power Consumption : <8W Power Saving Mode : <0.5W Power Off Mode : <0.3W Voltage : 100-240V, 50/60Hz |
Mechanical Design |
Height Adjustment : No Tripod Socket : Yes |
Dimensions (Esti.) |
Phys. Dimension without Stand (W x H x D) : 360.14 x 225.64 x 11.8 mm Box Dimension (W x H x D) : 434 x 290 x 76mm |
Weight (Esti.) |
Net Weight without Stand : 780g Gross Weight : 1.7kg |
Accessories (varies by region) |
Quick start guide USB-C cable Warranty Card ZenScreen sleeve |
Certificate |
TÜV Flicker-free TÜV Low Blue Light |
