2TB SPATIUM M480, 7000 / 6800 MB/s, 3D NAND, PCIe NVMe 4.0 x4, M.2 2280 SSD
Quantity:
- SKU: 14623273
- Manufacturer: MSI
- MPN: SM480N2TB
- Availability: TEMPORARILY OUT OF STOCK
Starting At
$198.92
2TB SPATIUM M480, 7000 / 6800 MB/s, 3D NAND, PCIe NVMe 4.0 x4, M.2 2280 SSD
A NEED FOR SPEED!
Optimized for the PCIe Gen4 interface, SPATIUM M480 SSD reaches read/write speeds up to 7000/6800 MB/s, allowing for rapid data transfer and shortened game load times.
- PCIe Gen4x4 interface and complies with the NVMe 1.4 standard
- Sequential Read speeds up to 7000MB/s and Write speeds up to 6800MB/s
- Up to 1400 TBW
- Built-in data security and error-correction capabilities
- 500GB to 2TB capacities in M.2 2280 form factor
- Suitable for both desktop and notebook
- 5-Year Warranty
| Differences are marked in red | SPATIUM M480 PCIe 4.0 NVMe M.2 2TB |
| Model Name | SPATIUM M480 PCIe 4.0 NVMe M.2 |
| Capacity | 2TB |
| Controller | PHISON E18 |
| Flash Memory | 3D NAND |
| DRAM Cache | 2GB DDR4 |
| Form Factor | M.2 2280 |
| Interface | PCIe Gen4x4, NVMe 1.4 |
| Compatibility | PCIe Gen4 / Gen3 / Gen2 / Gen1 |
| Dimensions | 80.00mm (L) x 22.00mm (W) x 2.15mm (H) |
| Sequential Read up to (MB/s) | 7000 |
| Sequential Write up to (MB/s) | 6800 |
| Random Read 4KB up to (IOPS) | 650,000 |
| Random Write 4KB up to (IOPS) | 700,000 |
| Maximum Operating Power (W) | 8.2 |
| Idle Power PS3 (mW) | 22 |
| Low Power L1.2 (mW) | 3 |
| Operating Temperatures | 0°C – 70°C |
| Storage Temperatures | -40°C – 85°C |
| Terabytes Written (TBW) | 1400 |
| Mean Time Between Failure (MTBF) | Up to 1,600,000 Hours |
| Limited Warranty | 5 Years, or the coverage for the maximum TBW as stated, whichever comes first. |
| Advanced Features |
TRIM (Performance Optimization, OS support required) SMART (Self-Monitoring, Analysis and Reporting Technology) LDPC (Low Density Parity Check) ECC Algorithm End to End Data Path Protection APST (Autonomous Power State Transition) AES256/TCG OPAL2.0/Pyrite (Encryption, Data Security) |
