Type |
Product Type |
SSD |
Series |
970 EVO Plus |
Usage Application |
Client PCs |
Interface |
PCIe Gen 3.0 x 4, NVMe 1.3 |
Application |
Consumer |
Yes |
Storage |
Capacity |
500GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
Key Features |
Sequential Read Speed |
Up to 3,500 MB/s * Performance may vary based on system hardware & configuration |
Sequential Write Speed |
Up to 3,200 MB/s * Performance may vary based on system hardware & configuration |
Random Read Speed |
Random Read (4KB, QD32): Up to 480,000 IOPS; Random Read (4KB, QD1): Up to 19,000 IOPS * Performance may vary based on system hardware & configuration |
Random Write Speed |
Random Write (4KB, QD32): Up to 550,000 IOPS; Random Write (4KB, QD1): Up to 60,000 IOPS * Performance may vary based on system hardware & configuration |
Controller |
Samsung Phoenix Controller |
NAND Flash |
Samsung V-NAND 3-bit MLC |
Cache Memory |
Samsung 512MB Low Power DDR4 SDRAM |
Trim Support |
Supported |
AES Encryption |
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
S.M.A.R.T. Support |
Supported |
GC (Garbage Collection) |
Auto Garbage Collection Algorithm |
WWN Support |
Not supported |
Device Sleep Mode Support |
Yes |
Temperature proof |
Yes |
NVMe |
Yes |
Gaming SSDs |
Yes |
General |
Average Power Consumption (system level) |
* Average: 5.8 W * Maximum: 9 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration |
Power consumption (Idle) |
Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration |
Voltage |
3.3 V ± 5 % Allowable voltage |
Reliability (MTBF) |
1.5 Million Hours Reliability (MTBF) |
Environmental Specs |
Operating Temperature |
0 - 70 °C Operating Temperature |
Shock |
1,500 G & 0.5 ms (Half sine) |
Form Factor |
Product |
M.2 (2280) |
Dimensions (W x H x D) |
Product |
80.15 x 22.15 x 2.38 (mm) |
Weight |
Product |
Max 8.0 g Weight |
Software |
Management SW |
Magician Software for SSD management |
Warranty |
Product |
5-Year Limited Warranty or: 300 TBW Limited Warranty |
