Dark Base Pro 901, Tempered Glass, No PSU, E-ATX, White, Full Tower Case
Quantity:
- SKU: 17517278
- Manufacturer: be quiet!
- MPN: BGW51
- Availability: USUALLY SHIPS WITHIN 3-5 DAYS
Starting At
$315.55
Dark Base Pro 901, Tempered Glass, No PSU, E-ATX, White, Full Tower Case
Outstanding Versatility, Performance and Silence
Dark Base Pro 901 White is the epitome of a flexible, yet user-friendly case.
- Interchangeable top cover and front panel for either maximum airflow or virtually inaudible operation
- Fan and radiator brackets with integrated fan hub in front and top make installation a breeze
- 3 Silent Wings 4 140mm PWM White fans for a virtually inaudible operation and high performance
- Touch-sensitive I/O panel for state-of-the-art operation
- Generous dimensions ensure operation of E-ATX motherboards and radiators up to 420mm
- Well-conceived system for an extremely user-friendly handling
- Flexible motherboard tray for an inverted layout
- Subtle ARGB lighting in the front and the PSU Shroud
| General data | |
| Model | Dark Base Pro 901 |
| Color option | White |
| Motherboard compatibility | E-ATX / XL-ATX / ATX / M-ATX / Mini-ATX |
| Case size excl. stands (L x W x H), (mm) | 604 x 254 x 539 |
| Case size incl. stands (L x W x H), (mm) | 604 x 275 x 569 |
| Volume (l) | 82.69 |
| PSU form factor | ATX PS/2 |
| Weight (kg) | 18 |
| Expansion slots | 8 |
| Pre-installed fans | |
| Fan at top | - |
| Fan at front | 2x Silent Wings 4 140mm PWM |
| Fan at side | - |
| Fan at rear | 1x Silent Wings 4 140mm PWM |
| Fan at bottom | - |
| Dimensions (L x W x H), (mm) | Front: 140 x 140 x 25 / Rear: 140 x 140 x 25 |
| Fan speed at 100% PWM / 12V (rpm) | 1900 |
| Airflow at 100% PWM / 12V (CFM / m3/h) | 78.4 / 133.20 |
| Air Pressure at 100% PWM / 12V (mm H2O) | 2.36 |
| Noise level at 100% PWM / 12V (dB(A)) | 29.3 |
| Voltage range (V DC) | 12 |
| Input power (W) | 4.8 |
| Input current (A) | 0.4 |
| Connector | 4-pin PWM |
| Lifespan (h / 25°C) | 300,000 |
| Fan controller | - |
| Maximum fan installation | |
| Maximum fans | 11 |
| Top (mm) | 3x 140 / 3x 120 |
| Front (mm) | 3x 140 / 3x 120 |
| Side (mm) | 3x 120 |
| Rear (mm) | 1x 140 / 1x 120 |
| Bottom (mm) | 1x 140 / 1x 120 |
| PSU shroud | - |
| Optional radiator installation | |
| Top (mm) | 120 / 240 / 360 |
| Front (mm) | 120 / 140 / 240 / 280 / 360 / 420 |
| Side (mm) | 120 / 240 / 360 |
| Rear (mm) | 120 / 140 |
| Bottom (mm) | - |
| PSU compatibility | |
| Maximum dimensions excl. bottom fan (mm) | 325 |
| Maximum dimensions incl. bottom fan (mm) | 325 |
| Graphics card | |
| HDD cage (in height of graphics card) installed (mm) | 350 / 370 |
| HDD cage (in height of graphics card) removed (mm) | 495 |
| Maximum PCIe slots with vertical graphics card (pcs.) | 8 |
| Drive bay capacity | |
| 5.25 bays (pcs.) | 1 |
| 3.5 slots (scope of delivery) | 2 |
| 3.5 slots (max.) | 7 |
| 2.5 slots (scope of delivery) | 6 |
| 2.5 slots (max.) | 16 |
| Cooling | |
| Max.construction height of CPU cooler unit (mm) | 190 |
| Airflow channel | - |
| Lighting | |
| LED illumination | Yes |
| LEDs (pcs.) | 8 + 16 |
| LED type | ARGB - 5V |
| LEDs synchronizable with controller/motherboard | Yes |
| I/O Panel | |
| USB 3.2 Gen. 2 Type C | 1 |
| USB 3.2 Type A | 4 |
| USB 2.0 | - |
| HD Audio I/O | Mic + Audio |
| Qi charger / Quick Charging Option | 15W |
| Insulation and damping | |
| Top panel insulation mats | √ |
| Front panel insulation mats | √ |
| Side panel insulation mats | √ |
| Anti-vibration decoupled HDD | √ |
| Anti-vibration decoupled fan | √ |
| Anti-vibration decoupled PSU | √ |
| Anti-vibration decoupled motherboard-tray | √ |
| Scope of delivery | |
| Screw set (Drives/Motherboard) | √ |
| Additional standoffs (pcs.) | 3 (for E-ATX) |
| SSD bracket for PSU shroud | - |
| LED strips (pcs.) | 0 |
| Cable ties (pcs.) | 12 |
| Screw box | √ |
| VGA holder | √ |
| VGA holder for inverted layout | √ |
| Mesh Front Panel | √ |
| ODD Bracket | √ |
| Fan / Radiator bracket for multi mounting panel | √ |
| Removeable dust filters | |
| Top | - |
| Front | 1 |
| Side | 0 |
| Bottom | 1 |
| Material | |
| Top cover | Aluminium |
| Front panel | Aluminium |
| Side panel | Glas |
| Side panel window | Steel |
| Stands | Steel |
| Safety certification | |
| Approvals | CE, UKCA |
| Environmental directives | |
| RoHS | √ |
| Reach | √ |
| WEEE | √ |
| Triman | √ |
| Service | |
| Warranty (Years) | 3 |
| International hotline / free of charge | √ / DE, FR |
| Logistics data and RRP | |
| Article number | BGW51 |
| EAN code | 4260052191118 |
| Dimensions, package (L x W x H), (mm) | 633 x 357 x 684 |
| Gross weight, package (kg) | 21.3 |
