Dark Rock TF 2, 134mm Height, 230W TDP, Copper/Aluminum CPU Cooler
Quantity:
- SKU: 14580556
- Manufacturer: be quiet!
- MPN: BK031
- Availability: USUALLY SHIPS WITHIN 1-3 WEEKS
Starting At
$102.29
As low as $8.52/ Month*
Dark Rock TF 2, 134mm Height, 230W TDP, Copper/Aluminum CPU Cooler
NO COMPROMISE SILENCE AND PERFORMANCE
Dark Rock TF 2 offers extreme cooling performance for the CPU and surrounding components as well as virtually inaudible operation.
- Extremely high cooling performance with 230W TDP
- Two heat sinks with anti-vibration rubber inserts
- Six high-performance 6mm heat pipes
- Silent Wings 3 135mm with funnel shaped air-inlet and a Silent Wings 135mm for virtually inaudible operation of max. 27.1dB(A)
- Optimized mounting system makes for an easy installation
- Special black coating with ceramic particles enables perfect heat transfer
- Brushed aluminum top cover for elegant look
- Three-year manufacturer’s warranty
- Product conception, design and quality control in Germany
| General data | |
| Model | Dark Rock TF 2 |
| Overall dimensions without mounting material (L x W x H), (mm) | 163 x 140 x 134 |
| Total weight (kg) | 0.945 |
| TDP (W) | 230 |
| Socket compatibility AMD | AM4 / AM3(+) |
| Socket compatibility Intel | 1200 / 2066 / 1150 / 1151 / 1155 / 2011(-3) Square ILM |
| Fan model, number | 1x Silent Wings 3 135mm PWM / 1x Silent Wings 135mm PWM |
| Decoupled fan mounting | - |
| Overall noise level (dB(A)) @ 50/75/100% (rpm) | 11.1 / 19.7 / 27.1 |
| Heatsink specifications | |
| Dimensions (L x W x H), (mm) | 163 x 140 x 109 |
| Number of fins | top: 62 / bottom: 64 |
| Fin material | Aluminum |
| Base material | Copper |
| CPU contact surface | CNC machined |
| Heatpipe number / Diameter (mm) | 6 / 6 |
| Color | Black |
| Surface treatment | Ceramic coating |
| Fan specifications | |
| Fan dimensions (mm) | 135 x 135 x 22 / 135 x 135 x 25 |
| Speed @ 100% PWM /12V (rpm) | 1400 / 1300 |
| Bearing technology | Fluid Dynamic Bearing |
| Motor technology | 6-pole fan motor |
| Rated Voltage (V) | 12 |
| Input current (A) | 0.2 / 0.4 |
| Input power (W) | 2.4 / 4.8 |
| Connector | 4-pin PWM |
| Cable length (mm) | 220 |
| Lifespan (h / 25°C) | 300,000 |
| Accessories | |
| Thermal grease | Included |
| Mounting set | Intel & AMD |
| Y-Cable | - |
| User manual languages | CN, DE, EN, ES, FR, JP, PL, RU, TW |
| Service | |
| Warranty (Years) | 3 |
| International hotline / free of charge | - |
| Logistics data, RRP | |
| Article number | BK031 |
| EAN code | 4260052188705 |
| Dimensions, package (L x W x H), (mm) | 210 x 190 x 230 |
| Gross weight, package (kg) | 1,615 |
