Manufacturer: Fractal Design
Meshify strikes an aggressive pose in the Fractal Design lineup with unparalleled cooling performance and a defiant new look. Like black diamond facets, the angular asymmetry of the Meshify C Mini – Dark TG carves a space uniquely its own as a new force in high-airflow design. Tempered glass with a distinctive tint completes the stealth-inspired black-on-black aesthetic with exceptional style.
A compact yet spacious open Micro ATX layout creates an unrestricted airflow path from front intakes directly through key components to exhaust, ensuring heat is never an issue.
The Meshify C Mini – Dark TG has a remarkably compact footprint with the high-end component support of a larger tower, and with six fan mounts and multi-radiator liquid cooling capability, it has the cooling capacity to match.
When performance is top priority and compromise is not an option, Meshify has you covered in style.
|3.5" or 2.5" Drive capacity||2|
|Dedicated 2.5" drive capacity||3|
|Motherboard compatibility||mATX, ITX|
|Power supply type||ATX|
|Total fan mounts||7|
|Front fan||3x 120 or 2x 140 1x Dynamic X2 GP-12 included|
|Top fan||2x 120/140|
|Rear fan||1x 120 1x Dynamic X2 GP-12 included|
|Bottom fan||1x 120|
|Dust filters||Bottom fan + PSU Front fans Top panel|
|Front radiator||120/240mm 140/280mm (max width 144mm)|
|Top radiator||120/240mm (max component height on motherboard 40 mm)|
|Rear radiator||120mm (max width 125mm)|
|Power supply depth limit||Maximum 175mm recommended|
|Graphics card length limit||Max 315mm with front fan mounted|
|CPU cooler height limit||172mm|
|Cable routing||15-35mm space|
|Cable routing grommets||Yes|
|Fixed Velcro straps||Yes|
|Captive thumbscrews||Both side panels SSD brackets|
|Left side panel||Tempered glass panel|
|Case dimensions (LxWxH)||395 x 212 x 399 mm|
|Case dimensions w feet/protrusions/screws||409 x 217 x 412 mm|
|Net weight||6.28 kg|
|Package dimensions (LxWxH)||502 x 295 x 484mm|
|Package weight||7.41 kg|
