Radeon™ RX 6900 XT OC Formula 16G, 2125 - 2475MHz, 16GB GDDR6, Graphics Card
Quantity:
- SKU: 14515319
- Manufacturer: ASROCK
- MPN: RX6900XT OCF 16G
- Availability: TEMPORARILY OUT OF STOCK
Starting At
$1,097.08
Radeon™ RX 6900 XT OC Formula 16G, 2125 - 2475MHz, 16GB GDDR6, Graphics Card
ASRock Radeon™ RX 6900 XT OC Formula 16G. All-Metal Cover Design. Metal black & Metal grey with slight luxurious green for unique elegant All-Metal Cover Design also provide extra cooling of the graphics card.
-
Clock: GPU / Memory
GPU Clock P BIOS(Boost/Game): Up to 2475/ Up to 2295 MHz
GPU Clock Q BIOS(Boost/Game): Up to 2365/ Up to 2165 MHz
Base Clock: 2125 MHz -
Key Specifications
7nm AMD Radeon™ RX 6900 XT Graphics
16GB 256-bit GDDR6
AMD RDNA™ 2 Architecture
Hardware Raytracing1
PCI® Express 4.0 Support
3 x 8-pin Power Connectors
3 x DisplayPort™ 1.4 with DSC / 1 x HDMI™ 2.1 VRR -
Key Features
All-Metal Cover
21 Phase Power Design
OC Formula 3X Cooling System
Striped Axial Fan
Dual BIOS
Stylish Metal Backplate
0dB Silent Cooling
Super Alloy Graphics Card
Polychrome SYNC
| Graphics Engine | - AMD Radeon™ RX 6900 XT Graphics |
| Bus Standard | - PCI® Express 4.0 x16 |
| DirectX | - 12 Ultimate |
| OpenGL | - 4.6 |
| Memory | - GDDR6 16GB |
| Engine Clock |
- GPU Clock P BIOS(Boost/Game): Up to 2475/ Up to 2295 MHz - GPU Clock Q BIOS(Boost/Game): Up to 2365/ Up to 2165 MHz - Base Clock: 2125 MHz |
| Stream Processors | - 5120 |
| Compute Units | - 80 |
| Memory Clock | - 16 Gbps |
| Memory Interface | - 256-bit |
| Resolution | - Digital Max Resolution: 7680 x 4320 |
| Interface |
- 1 x HDMI™ 2.1 VRR - 3 x DisplayPort™ 1.4 with DSC |
| HDCP | - Yes |
| Multi-view | - 4 |
| Recommended PSU | - 1000W |
| Power Connector | - 3 x 8-pin |
| Accessories |
- 1 x Quick Installation Guide - 1 x Graphics Card Holder |
| Dimensions | - 332x137x61mm, 3-slot |
| Net Weight | - 1784 g |
