Specifications |
SATA 6 Gb/s |
Capacity |
14TB |
SED Model FastFormat (512e/4Kn) |
ST14000NM003G |
Features |
Helium Sealed-Drive Design |
Yes |
Protection Information (T10 DIF) |
— |
SuperParity |
Yes |
Low Halogen |
Yes |
PowerChoice™ Idle Power Technology |
Yes |
PowerBalance™ Power/Performance Technology |
Yes |
Hot-Plug Support |
Yes |
Cache, Multi-segmented (MB) |
256 |
Organic Solderability Preservative |
Yes |
RSA 2048 Firmware Verification (SD&D) |
Yes |
Reliability/Data Integrity |
Mean Time Between Failures (MTBF, hours) |
2 500 000 |
Reliability Rating @ Full 24×7 Operation (AFR) |
0,35% |
Non-recoverable Read Errors per Bits Read |
1 sector per 10E15 |
Power-On Hours per Year (24×7) |
8 760 |
512e Sector Size (Bytes per Sector) |
512 |
4Kn Sector Size (Bytes per Sector) |
4,096 |
Limited Warranty (years) |
5 |
Performance |
Spindle Speed (RPM) |
7,200 RPM |
Interface Access Speed (Gb/s) |
6.0, 3.0 |
Max. Sustained Transfer Rate OD (MB/s, MiB/s) |
261, 249 |
Random Read/Write 4K QD16 WCD (IOPS) |
170/440 |
Average Latency (ms) |
4,16 |
Interface Ports |
Single |
Rotation Vibration @ 20-1500 Hz (rad/sec²) |
12,5 |
POWER CONSUMPTION |
Idle A (W) Average |
5 W |
Max Operating, Random Read/Write 4K/16Q (W) |
10.0, 6.3 |
Power Supply Requirements |
+12 V and +5 V |
Environmental |
Temperature, Operating (°C) |
5°C – 60°C |
Vibration, Non-operating: 2 to 500 Hz (Grms) |
2,27 |
Shock, Operating 2 ms (Read/Write) (Gs) |
50 |
Shock, Non-operating 2 ms (GS) |
200 |
Physical |
Height (mm/in, max) |
26.11 mm/1.028 in |
Width (mm/in, max) |
101.85 mm/4.01 in |
Depth (mm/in, max) |
147 mm/5.787 in |
Weight (lb/g) |
670 g/1.477 lb |
Carton Unit Quantity |
20 |
Cartons per Pallet / Cartons per Layer |
40/8 |
