1TB FireCuda 530, w/ Heatsink, 7300 / 6000 MB/s, 3D TLC NAND, PCIe NVMe 4.0 x4, M.2 2280 SSD

Quantity:
  • SKU: 14630322
  • Manufacturer: SEAGATE
  • MPN: ZP1000GM3A023
  • Availability: TEMPORARILY OUT OF STOCK
Starting At
$305.88
Quantity:
1TB FireCuda 530, w/ Heatsink, 7300 / 6000 MB/s, 3D TLC NAND, PCIe NVMe 4.0 x4, M.2 2280 SSD

FireCuda 530 Heatsink 1TB

FireCuda 530 with heatsink offers a minimalist design, anodized aluminum body, and finely textured micropore surface to improve heat transfer and lower SSD temps—making it super-efficient at maximum cooling to maintain peak performance for longer periods of time.
FireCuda 530 with heatsink is also compatible with PS5â„¢ systems. Our built-in SSD and heatsink combo meets PS5 specs on performance and dimensions.

  • Blistering transfer speeds of up to 7300MB/s
  • Absolute power to make content creations apps run faster and smoother
  • Lightning-fast video rendering and exporting
  • Responsive performance built for accelerated gaming and sustained abuse—record, download, rewrite, repeat
Specifications 1TB
Standard Model (TCG Pyrite) ZP1000GM30023
Interface PCIe Gen4 ×4 NVMe 1.4
NAND Flash Memory 3D TLC
Form Factor M.2 2280 with heatsink 1
Performance
Sequential Read (Max, MB/s), 128KB2 7300
Sequential Write (Max, MB/s), 128KB2 6000
Random Read (Max, IOPS), 4KB QD32
T82
1,000,000
Random Write (Max, IOPS), 4KB QD32
T82
1,000,000
Endurance/Reliability
Total Bytes Written (TB) 1275
Mean Time Between Failures (MTBF, hours) 1,800,000
Rescue Data Recovery Services
(years)3
3
Warranty, Limited (years) 5
Power Management
Active Power, Average (W) 6.5
Idle Power PS3, Average (mW) 16
Low Power L1.2 mode (mW) <5
Environmental
Temperature, Operating Internal (°C) 0°C – 70°C
Temperature, Nonoperating (°C) -40°C – 85°C
Shock, Nonoperating: 0.5ms (Gs) 1500
Special Features
TRIM Yes
S.M.A.R.T. Yes
Halogen Free Yes
RoHS Compliance Yes
Physical
Length (mm/in, max) 80.15mm/3.156in
Width (mm/in, max) 24.2mm/0.953in
Height (mm/in, max) 9.84mm/0.388in
Weight (g/lb) 47g/0.104lb
1 Please verify that your system provides enough space for installation. The FireCuda 530 with heatsink exceeds dimensions of a standard M.2 2280 form factor. Heatsink is pre-installed and should not be removed
as it can damage the SSD.
2 Fresh out of box (FOB) performance obtained on newly formatted drive. Performance may vary based on SSD’s firmware version, system hardware, and configuration. Performance based on CrystalDiskMark v.7.0.0 x64 on Windows 10 host with PCIe Gen4 motherboard.
3 Rescue Data Recovery Services not available in all countries.
