The Intel® Solid State Drive Data Center Family for SATA expands with the Intel® SSD DC S3610 Series. The Intel SSD DC S3610 Series offers the next generation of data center SSDs optimized for mixed read-write performance, endurance,
and strong data protection.
The Intel SSD DC S3610 Series accelerates data center performance with read/write throughput speeds up to 550/5201 megabytes per second (MB/s) and 4K random read/write input/output operations per second (IOPs) up to 84,000/28,0001.
Applications benefit from 55 µs typical latency with max read latencies2 of 500 µs 99.9 percent3 of the time. Combining performance with low typical active power (less than 6.8 watts1 4) the Intel SSD DC S3610 Series improves data
center efficiency with superior quality of service and reduced energy costs.
Essentials | |
Status | Launched |
Launch Date | Q1'15 |
Sequential Read | 550 MB/s |
Sequential Write | 520 MB/s |
Random Read (8GB Span) | 84000 IOPS |
Random Write (8GB Span) | 28000 IOPS |
Latency - Read | 55 µs |
Latency - Write | 66 µs |
Power - Active | 6.0 W |
Power - Idle | 0.6 W |
Vibration - Operating | 2.17 GRMS (5-700 Hz) Max |
Vibration - Non-Operating | 3.13 GRMS (5-800 Hz) Max |
Shock (Operating and Non-Operating) | 1,000 G (Max) at 0.5 msec |
Operating Temperature Range | 0°C to 70°C |
Weight | 88 grams ± 2 grams |
Mean Time Between Failures (MTBF) | 2,000,000 Hours |
Uncorrectable Bit Error Rate (UBER) | 10^17 |
Warranty Period | 5 yrs |
Package Specifications | |
Capacity | 800 GB |
Form Factor | 2.5" 7mm |
Interface | SATA 3.0 6Gb/S |
Lithography | 20 nm |
Advanced Technologies | |
Enhanced Power Loss Data Protection | Yes |
Hardware Encryption | AES 256 bit |
High Endurance Technology (HET) | Yes |
Temperature Monitoring and Logging | Yes |
End-to-End Data Protection | Yes |
