Connections | |
---|---|
Inputs | 2 x 12G-SDI: Supports single link and dual link 4:2:2/4:4:4, 16 Channels embedded audio 1 x Ref/Sync: Black burst in SD, 720p50, 720p59.94, 1080i50 and 1080i59.94 formats or Tri-Sync in any HD format |
Outputs | 2 x 12G-SDI: Supports single link and dual link 4:2:2/4:4:4, 16 Channels embedded audio |
Computer Interface | PCI Express 2.0 x8 (compatible with x16 slots) |
Supported Formats | |
SD Format Support | 525/29.97 NTSC 625/25 PAL |
HD Format Support | 1280 x 720p50, 59.94, 60 1920 x 1080i50, 59.94, 60 1920 x 1080PsF23.98, 24, 25, 29.97, 30 1920 x 1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60 |
2K Format Support | 2048 x 1080PsF23.98, 24, 25 2048 x 1080p23.98, 24, 25 |
4K Format Support | 3840 x 2160p23.98, 24, 25, 29.97, 30, 50, 59.94, 60 4096 x 2160p23.98, 24, 25 |
Codec Support | AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, Apple ProRes 4444, Apple ProRes 422 (HQ), Apple ProRes 422, Apple ProRes (LT), Apple ProRes 422 (Proxy), Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10-bit 4:4:4 |
Other Specs | |
Compatible Software | DaVinci Resolve, Fusion, Final Cut Pro X, Premiere Pro CC, Avid Media Composer, After Effects CC, Avid Pro Tools, Steinberg Cubase, Autodesk Smoke, Photoshop CC, Nuke, Steinberg Nuendo, Avid Symphony, Avid News Cutter, Tools On Air just:in & live:cut & just:play & just:live, Softron OnTheAir, MovieRecorder and OnTheAir CG, Flash Media Live Encoder, Wirecast, Livestream Procaster, Resolume Avenue 4, Sony Vegas Pro, Corel VideoStudio Pro X4, CyberLink Power Director, MAGIX Video Pro X4, Vidblaster Pro & Studio & Broadcast, Uniplay, Playbox AirBox, CasparCG, Magicsoft CG, Xsplit Broadcaster, Imagine Communications Velocity & InfoCaster |
Compatible Operating Systems | Mac OS X 10.9 and newer Windows 7 and 8 Linux |
Environmental | Operating Temperature: 41 to 104&decF / 5 to 40°C Storage Temperature: -4 to 113°F / -20 to 45°C Relative Humidity: 0 to 90% non-condensing |
Certifications | EMC, UL, FCC, CE, C-Tick, KCC |
Form Factor | Length: 6.3" / 160 mm Height: Not Specified by Manufacturer |
Weight | 8.2 oz / 233 g |
Packaging Info | |
Package Weight | 0.7 lb |
Box Dimensions (LxWxH) | 6.8 x 5.4 x 1.3" |
