EK-Scalar Quad 2-slot - Acetal
EK-Scalar Terminal Quad 2-slot is a semi-parallel high-quality interconnection for connecting four (4) same type EK-Vector or EK-FC water blocks in a single, sturdy unit. Connecting multiple graphics has never been this easy and
aesthetically pleasing!
The Terminal is made of high-quality black POM acetal. There is no need to purchase additional links since the EK-Scalar terminal is mounted directly to the water block. Serial and parallel water flow is graphically explained in the
installation manual.
Included:
- 1x EK-Scalar Quad 2-slot - Acetal
- 2x Plug G1/4
- 1x mounting mechanism
For use with motherboards with PCIe x16 slots 40.6 mm (1.6") apart!
PLEASE NOTE:
- The EK-Scalar terminals are only compatible with EK-Vector and EK-FC blocks.
- To avoid cracking your EK plexi full cover water block, use only 0.5 - 0.7 Nm of torque force on the terminal screws.
- Do not use excessive force while fastening the terminal to the water block itself!
Additional Info
Threads | G1/4 |
---|
