Size |
120x120x25 mm |
Mounting hole spacing |
105x105 mm |
Connector & pin-configuration |
4-pin PWM |
Cable length |
40cm |
Bearing |
SSO2 |
Blade geometry |
Heptaperf™ |
Frame technology |
FocusedFlow™ |
Material |
Fibre-glass reinforced polyamide |
Ingress protection |
IP67 |
Motor type |
Three-phase |
Rotational speed (+/- 10%) |
2000 RPM |
Min. rotational speed (PWM, +/-20%) |
450 RPM |
Rotational speed @ 12V (+/- 10%) |
1050 RPM |
Airflow |
121,8 m³/h |
Acoustical noise |
29,7 dB(A) |
Static pressure |
3,94 mm H2O |
Max. input power |
1,68 W |
Max. input current |
0,07 A |
Operating voltage |
24 V |
Voltage PWM signal |
5 V |
MTTF |
> 150.000 h |
Scope of delivery |
|
Warranty |
6 years |
