Wireless-N 1T2R Half-height PCIe Mini Card

Quantity:
  • SKU: 9786475
  • Manufacturer: AzureWave
  • MPN: AW-NE104H
  • Availability: TEMPORARILY OUT OF STOCK
Starting At
$10.29
Quantity:
Wireless-N 1T2R Half-height PCIe Mini Card

AW-NE104H is the half-height wireless 11b/g/n 1T2R PCIe Mini card to be integrated with the new-generation notebook PC.
With AW-NE104H, the notebook PC can let users log on Internet wirelessly via the WLAN standard of 802.11b/g and 802.11n draft standard to deliver the data rate up to 300Mbps.

  • 300Mbps Data Rate:
    AW-NE104H delivers the data rate up to 300Mbps, which is ideal to build up the home or office networking environment
  • Backward Compatible with 802.11b and 802.11g wireless devices:
    AW-NE104H is fully compatible with all IEEE 802.11b and 802.11g-compliant products
  • Easy to Install:
    Friendly user interface with the step-by-step setup wizard to make the installation quick and easy
  • Secure Data Transmission
    AW-NE104H supports 64/128-bit WEP and WPA to secure the data transmission
Form Factor Half-height PCIe mini card
Operation Voltage 3.3V ± 5%
Antenna Connectors Two antenna connectors:
1) Main: (Tx/Rx)
2) Auxiliary (Rx)
Dimensions 26.65 (L) x 29.85 (W) x 3.15 (H) mm
Weight 0.13 ounces
Operating Environment Operating temperature: 0~80°C
Operating humidity: 50 ~ 92% non-condensing
WLAN Standard • IEEE 802.11n draft standard
• IEEE 802.11b/g
Modulation IEEE 802.11n/g
- OFDM
IEEE 802.11b
- CCK: 11, 5.5Mbps
- DQPSK: 2Mbps
- BPSK: 1 Mbps
Range 300m (open space)
100m (indoors)
Security 64/128-bit WEP and WPA
Frequency 2.412 ~ 2.472GHz, 2.484GHz
Network Architecture Ad-Hoc Mode (Peer to Peer)
Infrastructure Mode
Channel IEEE 802.11g/n:
Ch. 1~11: North America
Ch. 1~13: Japan
Ch. 1~13: Europe ETSI
Ch. 10~11: Spain
Ch. 10~13: France
IEEE 802.11b:
Ch. 1~11: North America
Ch. 1~14: Japan
Ch. 1~13: Europe ETSI
Ch. 10~11: Spain
Ch. 10~13: France
Output Power IEEE 802.11n Draft 2.0: 12 +/- 1.5 dBm
IEEE 802.11g: 14 +/- 1.5 dBm
IEEE 802.11b: 17 +/- 1.5 dBm
Receiver Sensitivity 802.11n Draft 2.0
HT20 MCS7 @ -64dBm
HT40 MCS7 @ -61dBm
802.11g: -70dBm (54Mbps)
802.11b: -80dBm (11Mbps)
Operating System Windows 7 and XP
Certification CE and FCC
