True Custom Computer Builder specializing in Assembly of Gaming Computers, Laptops, Workstations, Servers
MSI Radeon™ RX 6800 XT GAMING Z TRIO 16G (R6800XTGZT16). The latest iteration of MSI’s iconic GAMING series once again brings performance, low-noise efficiency, and aesthetics that hardcore gamers have come to recognize and trust. Now you too can enjoy all your favorite games with a powerful graphics card that stays cool and silent. Just the way you like it.
Boost Clock / Memory Speed
TRI FROZR 2 Thermal Design
RGB Mystic Light
Dragon Center
MODEL NAME | Radeon™ RX 6800 XT GAMING Z TRIO 16G |
GRAPHICS PROCESSING UNIT | Radeon™ RX 6800 XT |
INTERFACE | PCI Express® Gen 4 |
CUDA® CORES | 4608 Units |
CORE CLOCKS | Boost: Up to 2310 MHz / Game: Up to 2065 MHz |
MEMORY SPEED | 16 Gbps |
MEMORY | 16GB GDDR6 |
MEMORY BUS | 256-bit |
OUTPUT |
DisplayPort x 3 (v1.4) HDMI x 1 (Supports 4K@120Hz/8K@60Hz and VRR as specified in HDMI 2.1) |
HDCP SUPPORT | Y |
POWER CONSUMPTION | 300 W |
POWER CONNECTORS | 8-pin x 3 |
RECOMMENDED PSU | 750 W |
CARD DIMENSION (MM) | 324 x 142 x 55 mm |
WEIGHT (CARD / PACKAGE) | 1564g / 2230g |
DIRECTX VERSION SUPPORT | 12 |
OPENGL VERSION SUPPORT | 4.6 |
MULTI-GPU TECHNOLOGY | Y |
AFTERBURNER OC | Y |
MAXIMUM DISPLAYS | 4 |
VR READY | Y |
DIGITAL MAXIMUM RESOLUTION | 7680x4320 |
